Parts Listing
9
X510-5
ITEM PART
DESCRIPTION
NO. NUMBER
ITEM PART
DESCRIPTION
NO. NUMBER
1997-99 Dakota & Durango
610576-1 Standard 3.21 75812-5X 75935X 47071 707436X
610576-2 Standard 3.55 74346-5X 75934X 47069 707436X
610576-3 Standard 3.92 75813-5X 75934X 47069 707436X
610576-4 Standard 3.21 75812-5X 75935X 47071 707436X
610576-5 Standard 3.55 74346-5X 75934X 47069 707436X
610576-6 Standard 3.92 75813-5X 75934X 47069 707436X
Chrysler/Dodge 35/194 Front
Axle Axle Kits Shaft & Joint Assy.
Differential
Bill of
Material
Diff.
Type
Ratio
Ring Gear &
Pinion Kit (7)
Case Assy.
Kit (8)
Case Kit
Inner Parts
Kit
Right Hand
Shaft Assy.
Left Hand
Shaft Assy.
Bill of Material Table
NOTE: All Ring & Pinion Kits with base number 706930 are reverse spiral bevel
(7)
See Ring Gear & Pinion Kits in XGI Catalog for ratio & tooth combinations.
(8) See Differential Case Assy Kits in XGI Catalog for spline data & ratios.
1 -(3) Housing - Axle Service
2 -(1) Drive Pinion & Gear Assembly
3 701130X PKG - Inner Pinion Shim
4 707162X KIT - Inner Pinion Bearing
5 42102 Collapsible Spacer
6 706894X KIT - Outer Pinion Bearing
7 42778 Slinger - Outer Pinion Bearing
8 48009 Seal - Pinion Oil
9 48008 Seal - End Yoke
10 2-4-8131-1 End Yoke
11 44189 Pinion Nut
707438X KIT - Carrier Cover
12 -(4) Carrier Cover
13 41356 Plug - Carrier Cover
14 40286-5 Bolt - Carrier Cover (qty 10)
15 38615 RTV Silicone Sealant
16 -(3) Differential Bearing Cap
17 40284-1 Bolt - Differential Bearing Cap
18 706016X Differential Bearing Kit
19 701004X PKG - Differential Bearing Shim
20 -(1) Case - Differential (std)
21 41221 Bolt - Drive Gear (qty 10)
22 42570 Snap Ring
23 46504 Pinion - Differential
24 47559 Gear - Differential
25 34096 Thrustwasher - Differential Pinion
26 34095 Thrustwasher - Differential Gear
27 41648 Shaft - Differential Pinion
28 13449 Roll Pin - Differential Shaft
29 565977 Bearing
30 46485 Oil Seal
31 47067 Axle Shaft (LH)
32 47065 Axle Shaft (RH)
33 41962 Vent - Axle Shaft (RH)
(1) See "Bill of Material Table" below
(2) See "Variable Parts Table" within this section
(3) Contact Vehicle Manufacturer
(4) Not Sold Separately
N.I. = Not Illustrated
