Spicer Dodge 1999-2001 Light Duty Axle Applications - Manual (Page 29)

Parts Listing
27
X510-5
ITEM PART
DESCRIPTION
NO. NUMBER
ITEM PART
DESCRIPTION
NO. NUMBER
1998-2000 Viper
606014-1 Trac Lok 3.07 75402-5X 75499X - - 74788-1X 74788-2X
2000 1/2 Viper
606521-1 Trac Lok 3.07 80739-5 80740 - - 74788-1X 74788-2X
Chrysler/Dodge 44/216 ICA Rear
1 -(3) Housing - Axle Service
2 -(1) Drive Pinion & Gear Assembly
3 - PKG - Inner Pinion Bearing Shim
(select pkg. based on thickness req)
72922-1X Inner Pinion Shim (.030 to .034)
72922-2X Inner Pinion Shim (.035 to .039)
72922-3X Inner Pinion Shim (.040 to .044)
72922-4X Inner Pinion Shim (.045 to .049)
72922-5X Inner Pinion Shim (.050 to .054)
4 707064X KIT - Inner Pinion Bearing
5 43916 Collapsible Spacer
6 706123X KIT - Outer Pinion Bearing
7 42737 Thrustwasher - Bearing
8 42449 Seal - Pinion Oil
9 42501 Seal - End Yoke
10 3-4-12211-1 End Yoke Assembly (inc 9)
11 30275 Washer - Pinion Nut
12 30271 Pinion Nut
13 38615 RTV Silicone Sealant
14 -(3) Arm - Carrier Cover Support
15 44300 Screw - Carrier Cover
16 39527 Fill Plug
17 44780 Breather Vent
18 44467-2 Bushing - Carrier Cover
19 -(3) Differential Bearing Cap
20 41212 Bolt - Differential Bearing Cap
21 706988X KIT - Differential Bearing
22 701005X PKG - Differential Bearing Shim
23 -(1) Case - Differential
24 41221 Bolt - Drive Gear (qty 10)
25 41193 Pinion - Differential
26 46618 Gear - Differential
27 13338-3 Thrustwasher - Differential Pinion
28 41219 Shaft - Differential
29 13449 Lock - Differential Shaft
707018X KIT - Differential Plate & Disc
(inc items 30, 31, 32, 33)
30 -(4) Disc - Differential
31 -(4) Plate - Differential Pressure
32 -(4) Plate - Differential Dished
33 40835 Clip - Diff Clutch Retainer
34 -(1) Shaft - Inner Yoke (inc 35)
35 41218 Seal Defector - Inner Yoke Shaft
36 45670 Oil Seal
37 566002 Bearing - Yoke Shaft
38 41323-8 Snap Ring
Axle Axle Kits Shaft & Joint Assy.
Differential
Bill of
Material
Diff.
Type
Ratio
Ring Gear &
Pinion Kit (7) Case Assy.
Kit (8)
Case Kit
Inner Parts
Kit
Right Hand
Shaft Assy.
Left Hand
Shaft Assy.
Bill of Material Table
(7) See Ring Gear & Pinion Kits in XGI Catalog for ratio & tooth combinations.
(8) See Differential Case Assy Kits in XGI Catalog for spline data & ratios.
(1) See "Bill of Material Table" below
(2) See "Variable Parts Table" within this section
(3) Contact Vehicle Manufacturer
(4) Not Sold Separately
