Parts Listing
13
(1) See "Bill of Material Table" on next page
(2) See "Variable Parts Table" within this section
(3) Contact Vehicle Manufacturer
(4) Not Sold Separately
(5) Bearing Assembly 566008 was used in older models and is still available for service.
X510-5
ITEM
PART
DESCRIPTION
NO.
NUMBER
ITEM
PART
DESCRIPTION
NO.
NUMBER
Chrysler/Dodge 44/216 Disconnect Front
1
-(3)
Housing - Axle Service
2
-(1)
Drive Pinion & Gear Assembly
3
701112X
PKG - Inner Pinion Bearing Shim
4
706015X
KIT - Inner Pinion Bearing
5
44896
Collapsible Spacer
6
706030X
KIT - Outer Pinion Bearing
7
13575
Slinger - Outer Pinion Bearing
8
-(2)
Seal - Pinion Oil
9
-(2)
Seal - End Yoke
10
-(2)
End Yoke Assembly (inc 9)
11
30186
Washer - Pinion Nut
12
30185
Pinion Nut
707192X
KIT - Carrier Cover (inc 13,14,15)
13
-(4)
Carrier Cover
14
36472
Plug - Carrier
15
34279
Bolt - Carrier Cover (qty 10)
16
38615
RTV Silicone Sealant
17
-(3)
Differential Bearing Cap
18
48632-1
Bolt - Diff Bearing Cap
19
706032X
KIT - Differential Bearing
20
706086X
PKG - Differential Bearing Shim
21
-(1)
Case - Differential
22
41221
Bolt - Drive Gear (qty 10)
23
45872
Pinion - Differential
24
45870
Gear - Differential
25
13338-3
Thrustwasher - Differential Pinion
26
32121
Thrustwasher - Differential Gear
27
39194
Shaft - Differential
28
13449
Lock - Differential Shaft
29
48489
Seal - Tube (left side)
-(2)
KIT - Socket Assembly
(inc items 30, 31, 32, 33, 34)
30
500024-6
Cotter Pin
31
40584
Slotted Nut
32
40916
Upper Socket
33
-(2)
Lock Nut
34
-(2)
Lower Socket
35
-(2)
Stop Screw
36
-(2)
Jam Nut
37
-(3)
Knuckle (RH)
-(3)
Knuckle (LH)
38
44993-1
Bolt - Knuckle (if required)
39
-(1)
Shaft & Joint Assembly
40
45942
Slinger
41
-(2)
Shaft & Slinger/Tone Ring Assy.
42
-(3)
Hub Assembly
43
-(2)
Spacer - Flat
44
45523
Washer - Flat
45
46085
Slotted Nut
46
500025-10
Cotter Pin
47
50429(6)
Bushing - Synthetic
48
45770
Output Shaft
75265X
KIT - Front Axle Shaft (inc 48, 65)
49
500396-10
Bolt - Disconnect Assembly
50
500357-9
Lock Washer
51
-(3)
Brake Line Clip
52
43424
Protection Shield
-(3)
Cover & Motor Assembly
(inc 53,54,55,56,57,58,59,60,61)
53
-(4)
Motor Assembly
54
-(4)
O-Ring
55
-(4)
Cover - Housing
56
-(4)
O-Ring
57
-(4)
Switch Assembly
58
-(4)
Snap Ring
59
-(4)
Snap Ring
60
-(4)
Shift Fork
61
-(4)
Clip
62
46401
Clutch Collar
63
41494
Gasket
64
48488
Seal - Tube (right side)
65
43337
Bushing
66
50382
Oil Seal
