Spicer Dodge 1999-2001 Light Duty Axle Applications - Manual (Page 24)

Variable Parts Listing
X510-5
22
Kits & Parts - Use With All Applications
Bills of Material Description & Item Number (Refer to the
"Exploded View" at the front of this section)
Chrysler/Dodge 60/248 Front Disconnect
610788 610791 610794 610828 610829
610789
1 Seal - Pinion Oil 8 42449 42449 - 42449 42449
2 Seal - End Yoke 9 34592 34592 - 34592 34592
3 End Yoke Assy (inc 9) or Flange 10 2-4-7681-1X 2-4-7681-1X - 2-4-7681-1X 2-4-7681-1X
4 KIT - Carrier Cover - 707335X 707335X - 707335X 707335X
5 Pinion - Differential 23 46354 46354 - 46354 46354
6 Gear - Differential 24 46355 46355 - 46355 46355
7 Thrustwasher - Differential Gear 26 46146 46146 - 46146 46146
8 Seal - Tube (Left Side) 29 620216 620216 - 620216 620216
9 KIT - Socket Assembly - 707469X 707469X 708047 707469X 707469X
10 Nut - Slotted 31 44101 44101 41864 44101 44101
11 Bushing - 0º Caster 32 44507 44507 - 44507 44507
12 Upper Socket 33 40126 40126 49476 40126 40126
13 Lock Nut 34 44133 44133 35566 44133 44133
14 Lower Socket 35 44627 44627 49477 44627 44627
15 Snap Ring 36 620343 620343 49478 620343 620343
16 Bolt - Knuckle/Hub 39 45524 45524 - 45524 45524
17 Outer Shaft & Slinger Assembly 42 75689X - 80113 75689X 75689X
18 Spacer - Flat 47 45935 48355 - 45935 48355
19 Oil Seal 51 - - - - -
20 Clutch Collar 65 46401 46401 - 46401 46401
21 Seal - Tube (right side) 67 43154 43154 - 43154 43154
22 Output Shaft 68 45531 45531 - 45531 45531
23 Bearing Assy or Synthetic Bushing 69 566008 566008 - 566008 566008
610830 610831 610832 610836 610839
610837
610838
1 Seal - Pinion Oil 8 42449 - 42449 47885 -
2 Seal - End Yoke 9 34592 - 34592 47886 -
3 End Yoke Assy (inc 9) or Flange 10 2-4-7681-1X - 2-4-7681-1X 2-4-8421-1 -
4 KIT - Carrier Cover - 707335X - 707335X 708050 -
5 Pinion - Differential 23 46354 - 34367 46354 -
6 Gear - Differential 24 46355 - 34394 49482 -
7 Thrustwasher - Differential Gear 26 46146 - 34729 46146 -
8 Seal - Tube (Left Side) 29 620216 - 620216 49489 -
9 KIT - Socket Assembly - 707469X 707469X 707469X 708047 708047
10 Nut - Slotted 31 44101 44101 44101 41864 41864
11 Bushing - 0º Caster 32 44507 44507 44507 - -
12 Upper Socket 33 40126 40126 40126 49476 49476
13 Lock Nut 34 44133 44133 44133 35566 35566
14 Lower Socket 35 44627 44627 44627 49477 49477
15 Snap Ring 36 620343 620343 620343 49478 49478
16 Bolt - Knuckle/Hub 39 45524 45524 45524 49466 49466
17 Outer Shaft & Slinger Assembly 42 75689X 74777X 75689X 80375 80113
18 Spacer - Flat 47 48355 48355 45935 - -
19 Oil Seal 51 - - - 50381 -
20 Clutch Collar 65 46401 - 46401 49495 -
21 Seal - Tube (right side) 67 43154 - 43154 49485 -
22 Output Shaft 68 45531 - 45531 49490 -
23 Bearing Assy or Synthetic Bushing 69 566008 - 566008 49488 -
