Important: See Safety Information in General Information Section (J300P-GI)
J300P-1
HOW TO USE THIS CATALOG
To identify any splined companion fl ange, there are ten pieces of required information:
1.
Center Hole type (Splined, Round or Tapered hole)
2.
Spline size and tooth count
3.
Pilot diameter and type (Male / Female)
4.
Bolt circle diameter
5.
Bolt hole diameter and if the hole is drilled or tapped (drilled-D or tapped-T)
6.
Number of bolt holes
7.
Ground hub diameter (where applicable)
8.
Brake drum pilot diameter
9.
Length of through hole
10.
Flange face to end of hub
Example: to fi nd a companion fl ange with a 2.143-41 involute splined hole, a 7.750 female pilot
that includes twelve bolts:
1. Find
the
Splined Hole section of this catalog;
2. Find
the
2.143-41 Involute Spline sub-heading;
3.
Find the Female Pilot diameter of 7.750
4.
Find the Bolt circle diameter of 7.250
5.
Find the Drilled Bolt hole diameter of .440
6.
Find a Number of bolt holes of 12
7.
Find the Ground hub diameter of 2.939
8.
Find the Brake drum pilot diameter (not applicable in this example)
9.
Find the Length of through hole of 2.495
10.
Find the Flange face to end of hub of 3.500
Locate the part number that matches the dimension of your part: example 6.5-1-2941
Be sure to read any notes that are provided.
J300P-1
COMPANION FLANGES
Spline Hole
2.114-32 Involute Spline
2.114 5.312 M 6.125 .385 D 8
—
3.000 2.250 2.844 3 5-1-6731X 232200 5-1-6721 1610
.424 deep counterbore at hub end
2.114 6.625 F 6.125 .375 D 8
—
3.000 2.245 2.844 3 5-1-6701X
232200
5-1-6691
1610
.424 deep counterbore at hub end; 5-1-6691 will be replaced by 5-1-6701X when supply is exhausted
2.143-41 Involute Spline
2.143 7.750 F 7.250 .440 D 12
—
2.939 2.495 3.500 4
6.5-1-2941 1810
2.149-16 Spline
2.149 6.625 F 6.125 .385 D 8
—
2.938 3.000 3.750 3
5-1-2551• 1610
2
3
4
5
6
7
8
9
10
Part
Number
1
F
i
g
u
r
e
D
C
B
Bolt
Hole
E
F
G
Companion
Spline
Pilot
Brake
Flange
Flange
Companion
Hole Diameter Bolt Diameter
Drum Ground Length Face
Assembly
Slinger
Flange
Major F-Female
Circle D-Drilled # of
Pilot
Hub
Thru
to End
(includes slinger
Part
Part
Series
Diameter M-Male Diameter T-Tapped Holes Diameter Diameter Hole
of Hub
when listed)
Number
Number
