Page 16

16
Important: See Safety Information in General Information Section (J300P-GI)
J300P-1
COMPANION FLANGES
Rectangular Type—Straight Round Hole
D
K
C
E
F
G
Pilot
Flange
Companion
Diameter
Length
Face
Flange
Bore
Keyway
F-Female
Hole
Hub
Thru to
End
Part
Diameter
Width
M-Male
Diameter
At
Diameter
Hole
of
Hub
Number
Set Screw Hole
Viewed from Hub
End & Keyway at 12
•
Part is discontinued
Part is available until supply is exhausted
Not sold separately
1100 SERIES
A-3.500 B-2.750 DIA. (4 HOLES)
.875
.188
2.250-F
.375
6
1.875 1.500
2.125
1-1-253
.875
.250
2.250-F
.375
6
1.875 1.500
2.125
1-1-293•
1.000
.250
2.250-F
.375
6
1.875
1.500
2.125
1-1-143
1.125
.250
2.250-F
.375
6&9
1.875
1.500
2.125
1-1-153
1.125
.312
2.250-F
.375
6
1.875
1.500
2.125
1-1-123
1.250
.312
2.250-F
.375
6
1.875
1.500
2.125
1-1-273
1.250
.312
2.250-F
.375
3
1.875
1.500
2.125
1-1-653
1.375
.312
2.250-F
.375
6
2.125
1.500
2.125
1-1-473
1310 SERIES
A-3.875 B-3.125 DIA. (4 HOLES)
.875
.188
2.375-F
.375
6
1.875 1.500
2.062
2-1-623•
1.000
.250
2.375-F
.375
6
1.875
1.500
2.062
2-1-283
1.125
.250
2.375-F
.375
6&9
1.875
1.500
2.062
2-1-293
1.125
.312
2.375-F
.375
6
1.875
1.500
2.062
2-1-303•
1.250
.250
2.375-F
.375
6
1.875
1.500
2.062
2-1-323
1.250
.312
2.375-F
.375
6
1.875
1.500
2.062
2-1-333
1.375
.312
2.375-F
.375
6
2.120
1.500
2.062
2-1-903
Hub diameter not ground
1.500
.375
2.375-F
.375
6
2.438
2.000
2.625
2-1-933
1350 SERIES
A-4.562 B-3.750 DIA. (4 HOLES)
1.250
.312
2.750-F
.375
6
2.250
2.000
2.562
3-1-163
1.500
.375
2.750-F
—
—
2.250
2.000
2.562
3-1-333
1.750
.375
2.750-F
.375
12
2.812
—
3.438
3-1-463
3-1-463 was replaced by 3-1-303-7
1480 SERIES
A-5.875 B-4.750 DIA. (4 HOLES)
2.000
.375
3.750-F
—
—
3.000
2.750
3.590
4-1-1123•
Hub diameter not ground
1550 SERIES
A-5.750 B-4.750 DIA. (4 HOLES)
1.250
—
3.750-F
—
—
3.000
3.062
3.625
4-1-543
