11
Important: See Safety Information in General Information Section (J300P-GI)
J300P-1
COMPANION FLANGES
Spline Hole
• Part is discontinued „ Part is available until supply is exhausted Ž Not sold separately
F
i
g
u
r
e
D C B Bolt Hole E F G Companion
Spline Pilot Brake Flange Flange Companion
Hole Diameter Bolt Diameter Drum Ground Length Face Assembly Slinger Flange
Major F-Female Circle D-Drilled # of Pilot Hub Thru to End (includes slinger Part Part Series
Diameter M-Male Diameter T-Tapped Holes Diameter Diameter Hole of Hub when listed) Number Number
2.784-21 Involute Spline
2.784 6.438-M 7.250 .438D 16 — 3.500 3.000 4.125 6 — — 6-1-5231• 1710
Part has 16 equally spaced holes
2.784 7.750-F 7.250 D 12 — 3.375 3.125 4.440 1 — — 6.5-1-3021ƒ
3.000-10 Spline
3.000 7.750-F 7.250 .440D 12 — 4.000 3.062 3.750 4 — — 6.5-1-951
3.503-27 Involute Spline
3.503 6.888-M 11.024 .875D 8 — 5.003 4.185 5.850 2 315DIN-1-71X• 231574 315DIN-1-61Ž 315 DIN
Slinger not sold separately
3.503 7.000-F 8.250 .625D 8 — 5.005 4.000 5.188 5 8-1-791X 230922 8-1-751Ž 1880
Slinger not sold separately
