Power-Sonic PG-2v2700 User Manual
Pg range (vrla), 15yr design life in float service at 20 º c)

PG Range (VRLA)
Discharge Characteristics (25ºC, 77ºF)
Physical Specification
Internal Resistance mΩ
Dimensions (mm)
Standard terminal (mm)
Power-Sonic Europe Limited
3 Buckingham Square, Wickford, Essex, SS11 8YQ
Tel: +44 (0)1268 560686 Fax: +44 (0)1268 560902
www.power-sonic.co.uk
PG-2V2700
Nominal Voltage
Nominal Capacity
2V
2700 AH
Dimension
Length
Width
Container Height
Total Height (with terminal)
Weight
Standard Terminal
T11
Approx 151.5kg
350
490
339
349
2 mm
2 mm
2 mm
2 mm
+
-
+
-
+
+
-
Rated
Capacity
Capacity
Affected by
Temperature
Cycle
Standby
C
o
n
s
ta
n
t
V
o
lt
a
g
e
C
h
a
rg
e
Initial Charging Current
Less than 675.0A
Voltage 2.4V ~ 2.5V
at 25°C (77°F)
Recommended Charge
Current less than 675.0A
Voltage 2.25V ~ 2.3V
at 25°C (77°F)
40°C (104°F)
25°C (77°F)
0°C (32°F)
103%
100%
86%
Rev2 03/12
3
3
9
2
3
4
9
2
490
2
3
5
0
2
0.25mΩ
(15yr Design Life in Float Service at 20ºC)
In the event of further technical development we reserve the right to alter our design, specification and price without notice. E&O.E
20hRate(1.80V/cell) 2700.00AH
10hRate(1.80V/cell) 2500.00AH
8hRate(1.75V/cell) 2452.00AH
5hRate(1.75V/cell) 2175.00AH
1hRate(1.60V/cell) 1550.00AH
F.V/Time
10min
15min
20min
30min
45min
1h
2h
3h
4h
5h
6h
8h
10h
20h
1.85V/cell
2925.0
2460.0
2182.5
1810.0
1396.7
1195.0
773.8
581.8
476.6
401.0
351.3
281.8
242.3
129.3
1.80V/cell
3346.9
2762.4
2413.0
1965.9
1506.7
1261.4
831.8
625.0
506.6
425.0
372.2
296.6
250.0
135.0
1.75V/cell
3801.4
3113.4
2666.7
2136.3
1643.3
1375.0
865.0
650.0
524.1
435.0
383.8
306.5
256.7
137.1
1.70V/cell
\
3454.2
2943.5
2332.3
1770.0
1455.0
911.3
684.2
547.5
460.0
402.3
319.4
266.6
140.6
1.65V/cell
\
3698.4
3131.4
2461.3
1873.3
1505.0
944.8
711.7
569.1
474.5
416.3
330.2
274.1
145.0
1.60V/cell
\
\
3401.8
2626.4
1946.7
1550.0
968.8
730.0
581.8
486.1
425.0
335.9
279.8
147.4
Constant Current Discharge (Amperes) at 25 °C (77°F )
F.V/Time
10min
15min
20min
30min
45min
1h
2h
3h
4h
5h
6h
8h
10h
20h
1.85V/cell
5461.6
4639.6
4157.7
3486.1
2712.6
2328.9
1518.1
1145.6
941.4
794.1
697.6
562.1
484.3
258.6
1.80V/cell
6176.7
5140.6
4529.9
3728.9
2903.6
2445.3
1621.1
1223.9
995.3
837.8
736.2
589.7
499.0
267.2
1.75V/cell
6904.0
5723.4
4958.7
4019.0
3137.1
2653.5
1679.7
1267.9
1026.1
854.6
756.9
608.1
511.8
273.7
1.70V/cell
\
6262.5
5432.8
4363.8
3366.5
2799.0
1765.8
1332.1
1070.0
902.3
792.0
633.1
531.1
280.5
1.65V/cell
\
6654.1
5736.8
4567.7
3531.2
2874.6
1820.2
1379.7
1108.1
927.6
817.1
652.8
545.1
288.8
1.60V/cell
\
\
6165.0
4840.4
3650.0
2945.0
1857.5
1408.9
1129.2
946.9
831.7
662.8
555.6
293.1
Constant Power Discharge (Watts/cell) at 25°C (77°F )
20
M8
6
Torque 11.0 -14.7 Nm
T11 Threaded Insert 8mm Stud
