Power-Sonic PSGL-12170 User Manual
Psgl gel series, For cyclic applications), Approx 18 mω

Discharge Characteristics (25ºC, 77ºF)
Physical Specification
Internal Resistance mΩ
Dimensions (mm)
Standard terminal (mm)
Power-Sonic Europe Limited
3 Buckingham Square, Wickford, Essex, SS11 8YQ
Tel: +44 (0)1268 560686 Fax: +44 (0)1268 560902
www.power-sonic.co.uk
PSGL12170
Nominal Voltage
Nominal Capacity
12V
17.0 AH
Dimension
Weight
Standard Terminal
T12
Approx 5.8kg
Rated
Capacity
Capacity
Affected by
Temperature
17.00AH
15.50AH
14.88AH
13.60AH
9.93AH
Cycle
Standby
C
on
st
ant
V
ol
ta
g
e
C
harg
e
Initial Charging Current
Less than 4.25A
Voltage 14.4V ~ 15.0V
at 25°C (77°F)
Recommended Charge
Current less than 4.25A
Voltage 13.5V ~
13.8V at 15°C (77°F)
40°C (104°F)
25°C (77°F)
0°C (32°F)
103%
100%
86%
Approx 18 mΩ
(For cyclic applications)
20hr Rate(
1.80V/cell)
10hr Rate(
1.80V/cell)
8hr Rate(
1.75V/cell)
5hr Rate(
1.75V/cell)
1hr Rate(
1.60V/cell)
77
2
181
2
167.5
2
154
2
12
M5
6
T12 Threaded Insert 5mm Stud
Torque 2.0 -3.0 Nm
PSGL Gel Series
Self Discharge Characteristics
0
5
10
15
20
25
Storage time in months
20
40
60
80
100
120
40
30
20
10
Remaining capacity %
Rev1 2/13
Cycle Life in Relation to Depth of Discharge
Number of Cycles
30
40
60
80
Extracted capacity in %
20
10
50
70
90
100
800
1200
1600
2000
2400
2800
3200
3600
4000
400
200
In the event of further technical development we reserve the right to alter our design, specification and price without notice. E&O.E
Length
Width
Container Height
Total Height (with Terminal)
181.5
2mm
77
2mm
167.5
2mm
167.5
2mm
