Power-Sonic PS-630ST User Manual
Ps range, 5yr design life in float service at 20°c)
PS Range
Discharge Characteristics (25ºC, 77ºF)
Physical Specification
Internal Resistance mΩ
Dimensions (mm)
Standard terminal (mm)
Power-Sonic Europe Limited
3 Buckingham Square, Wickford, Essex, SS11 8YQ
Tel: +44 (0)1268 560686 Fax: +44 (0)1268 560902
www.power-sonic.co.uk
PS-630ST 6V 3.4AH
Nominal Voltage
Nominal Capacity (20HR)
6V
3.4 AH
Dimension
Length
Width
Container Height
Total Height (with terminal)
Weight
Standard Terminal
F1
Approx 0.67kg
134
34
60
66
2 mm
2 mm
2 mm
2 mm
+
-
+
-
+
+
-
Rated
Capacity
Capacity
Affected by
Temperature
20hr Rate(1.80V/cell) 3.40AH
10hr Rate( 1.80V/cell) 3.25AH
8hr Rate( 1.75V/cell)
3.17AH
5hr Rate( 1.75V/cell) 2.93AH
1hr Rate( 1.60V/cell) 2.21AH
Cycle
Standby
C
o
n
s
ta
n
t
V
o
lt
a
g
e
C
h
a
rg
e
Initial Charging Current
Less than 0.85A
Voltage 7.20V ~ 7.50V
at 25°C (77°F)
Recommended Charge
Current less than 0.85A
Voltage 6.75V ~
6.90V at 25°C (77°F)
40°C (104°F)
25°C (77°F)
0°C (32°F)
103%
100%
86%
4.75
6.35
3.2
0.8
F1
Rev6 - 04/13
-
+
6
0
2
6
6
2
134
2
34 2
28.0 mΩ
-
(5yr Design Life in Float Service at 20°C)
In the event of further technical development we reserve the right to alter our design, specification and price without notice. E&O.E
F.V/Time
5MIN
10MIN
15MIN
20MIN
30MIN
45MIN
1HR
2HR
3HR
4HR
5HR
6HR
8HR
10HR
20HR
1.60V
13.10
8.91
6.60
5.39
3.91
2.72
2.21
1.26
0.96
0.77
0.629
0.534
0.412
0.342
1.67V
11.30
7.96
5.99
4.95
3.63
2.58
2.11
1.21
0.91
0.73
0.599
0.517
0.405
0.335
1.70V
10.80
7.61
5.80
4.76
3.51
2.55
2.07
1.19
0.89
0.72
0.593
0.512
0.402
0.331
1.75V
9.80
6.98
5.44
4.53
3.37
2.45
2.00
1.14
0.87
0.70
0.585
0.502
0.396
0.328
0.172
1.80V
8.69
6.35
4.98
4.21
3.25
2.36
1.92
1.10
0.85
0.69
0.563
0.488
0.389
0.325
0.170
1.85V
6.47
4.97
4.12
3.56
2.75
2.03
1.71
1.01
0.79
0.64
0.525
0.455
0.367
0.307
0.168
F.V/Time
5MIN
10MIN
15MIN
20MIN
30MIN
45MIN
1HR
2HR
3HR
4HR
5HR
6HR
8HR
10HR
20HR
1.60V
21.77
15.17
11.53
9.67
7.13
5.03
4.17
2.40
1.83
1.48
1.21
1.04
0.80
0.67
0.00
1.67V
19.33
13.90
10.70
9.00
6.70
4.83
4.00
2.31
1.75
1.41
1.16
1.01
0.79
0.66
0.00
1.70V
18.57
13.37
10.40
8.70
6.50
4.80
3.93
2.28
1.72
1.39
1.15
1.00
0.79
0.65
0.00
1.75V
17.33
12.53
9.90
8.33
6.27
4.63
3.83
2.20
1.67
1.36
1.14
0.98
0.78
0.65
0.34
1.80V
15.73
11.60
9.17
7.83
6.10
4.50
3.67
2.13
1.65
1.34
1.10
0.96
0.77
0.64
0.34
1.85V
11.83
9.20
7.70
6.70
5.23
3.90
3.30
1.96
1.54
1.26
1.03
0.90
0.72
0.61
0.33
Constant Current Discharge Characteristics Unit: Amperes (25ºC, 77ºF)
Constant Power Discharge Characteristics Unit: (Watts/cell) (25ºC, 77ºF)
