Power-Sonic PSX12-8.5 User Manual

Psx series, Vrla 6yr design life at 20 ) ºc

background image

PSX Series

Designed for UPS Applications

Discharge Characteristics (25ºC, 77ºF)

Physical Specification

Internal Resistance mΩ

Dimensions (mm)

Standard terminal (mm)

PSX12-8.5 12V 8.5AH

Nominal Voltage

Nominal Capacity

12V

8.5 AH

Dimension

Length

Width

Container Height

Total Height (with terminal)

Weight

Standard Terminal

F2

Approx 2.75kg

151

65

94

100

2 mm

2 mm

2 mm

2 mm

+

-

+

-

+

+

-

Capacity

Affected by

Temperature

Standby

C

on

st

an

t

V

olt

age

Cha

rg

e

Recommended Charge
Current less than 2.12A
Voltage 13.5V ~
13.8V at 25°C (77°F)

40°C (104°F)

25°C (77°F)

0°C (32°F)

103%

100%

86%

Approx 18.0 mΩ

Power-Sonic Europe Limited

3 Buckingham Square, Wickford, Essex, SS11 8YQ

Tel: +44 (0)1268 560686 Fax: +44 (0)1268 560902

[email protected]

www.power-sonic.co.uk

Rev3 02/13

-

(VRLA 6yr Design Life at 20

)

ºC

94

2

100

2

+

-

151

2

43

2

65

2

Power

Rating

3hr to(1.67V/cell)

1hr to(1.67V/cell)

15min to(1.67V/cell)

26.16 Watts

68.70 Watts

193.20 Watts

6.35

7.95

3.4

0.8

F2

Constant Power Discharge Characteristics Unit: W atts / Cell (25ºC, 77ºF)

Constant Current Discharge Characteristics Unit: Amperes (25ºC, 77ºF)

In the event of further technical development we reserve the right to alter our design, specification and price without notice. E&O.E

F.V(V/cell)

15min

1H

3H

1.85

13.29

5.08

1.91

1.80

14.55

5.43

2.02

1.75

15.91

5.67

2.10

1.70

16.98

5.86

2.15

1.67

18.14

6.05

2.25

1.60

19.01

6.28

2.32

F.V(V/cell)

15min

1H

3H

1.85

24.74

9.81

3.76

1.80

26.87

10.38

3.95

1.75

29.00

10.86

4.08

1.70

30.56

11.16

4.19

1.67

32.20

11.45

4.36

1.60

33.27

11.83

4.47
