Power-Sonic PSX12-70 User Manual
Psx series, Vrla 10yr design life at 20 ) ºc
PSX Series
Designed for UPS Applications
Discharge Characteristics (25ºC, 77ºF)
Physical Specification
Internal Resistances mΩ
Dimensions (mm)
Standard terminal (mm)
PSX12-70 12V 70AH
Nominal Voltage
Nominal Capacity
12V
70 AH
Dimension
Length
Width
Total Height
Height of terminal
Weight
Standard Terminal
T6
Approx 21.0kg
348
167
178
162
2 mm
2 mm
2 mm
2 mm
+
-
+
-
+
+
-
Capacity
Affected by
Temperature
Standby
C
on
st
an
t
V
o
lt
a
ge
C
ha
rge
Recommended Charge
Current less than 17.5A
Voltage 13.5V ~
13.8V at 25°C (77°F)
40°C (104°F)
25°C (77°F)
0°C (32°F)
103%
100%
86%
Approx 7.3 mΩ
Power-Sonic Europe Limited
3 Buckingham Square, Wickford, Essex, SS11 8YQ
Tel: +44 (0)1268 560686 Fax: +44 (0)1268 560902
www.power-sonic.co.uk
Rev3 02/13
-
(VRLA 10yr Design Life at 20
)
ºC
Power
Rating
3hr to(1.67V/cell)
1hr to(1.67V/cell)
15min to (1.67V/cell)
204.8 Watts
494.7 Watts
1382.3 Watts
178
2
143
2
162
2
167
2
348
2
262
2
In the event of further technical development we reserve the right to alter our design, specification and price without notice. E&O.E
Constant Power Discharge Characteristics Unit: W atts / Cell (25ºC, 77ºF)
Constant Current Discharge Characteristics Unit: Amperes (25ºC, 77ºF)
F.V(V/cell)
15min
1H
3H
1.85
90.70
36.67
15.52
1.80
104.37
39.09
16.20
1.75
114.07
40.93
16.49
1.70
121.74
42.20
16.98
1.67
129.50
43.65
17.75
1.60
138.52
45.20
18.24
F.V(V/cell)
15min
1H
3H
1.85
169.27
70.71
30.46
1.80
192.16
74.98
31.62
1.75
207.39
78.09
32.01
1.70
218.35
80.32
32.88
1.67
230.38
82.45
34.14
1.60
242.31
84.88
35.02
16
M6
6
Torque 3.9 ~5.4 Nm
T6 Threaded Insert 6mm Stud
