Power-Sonic PS-850AAL - Manual

Sealed Nickel Cadmium Batteries Model: PS-850AAL
Specifications Dimensions
Nominal Voltage 1.2 Volt
Rated Capacity 850 mAh
Dimensions
Diameter in. (mm) 0.56 (14.1)
Height in. (mm) 1.89 (48.0)
Height with solder tabs 1.93 (49.0)
Weight Approx. 23 gm
Internal Resistance < 40 mΩ
Standard Charge (0.1C) 85 mA
Trickle Charge (0.03C)~(0.05C)
Fast Charge ΔV 425 mA
Recommended Std/Trickle Charge 20±5°C
Operating Fast Charge 20±5°C
Temperature Discharge 20±5°C
Range Storage -20°C to 45°C
Standard Discharge (0.2C) Cut Off Voltage 1.0V per cell
High Rate Discharge (1 C) Cut Off Voltage 1.0V per cell
Charging and Discharging Characteristics
Discharge Standard Charge
Fast Charge Trickle Charge
in. (mm)
We’ve Got The Power.™
All data subject to change without notice
