Power-Sonic PS-121100 User Manual
Terminals (mm), Features

Sealed Rechargeable
MODEL PS-121100 B
12 Volt 110.0 Amp. Hr.
370 Watts per Cell
Battery
www.power-sonic.com
B
AT
TE
RY
MU
ST B
E R
EC
YC
LE
D
Pb
NONSPILLABLE
MH20845
®
L
HT
H
W
20mm
7mm
M8
Tolerances are +/- 0.04 in. (+/- 1mm) and +/- 0.08 in. (+/- 2mm) for
height dimensions. All data subject to change without notice.
Physical Dimensions: in (mm)
Performance Specifi cations
N
ominal Voltage ........................................................................ 12 volts (6 cells)
Nominal Capacity
20-hr. (5.5A to 10.50 volts) .......................................................... 110.0 AH
10-hr. (10.3A to 10.50 volts) ........................................................ 103.0 AH
5-hr.
(17.7A to 10.20 volts) .......................................................... 88.5 AH
1-hr.
(61.8A to 9.00 volts) ............................................................. 61.8 AH
15-min. (204A to 9.00 volts) ................................................................51.0 AH
Approximate Weight ...................................................... 69.50 lbs. (31.52 kg)
Energy Density (20-hr. rate) .............................. 1.81 W-h/in3 (110.26 W-h/l)
Specifi c Energy (20-hr. rate) .............................. 18.99 W-h/lb (41.87 W-h/kg)
Internal Resistance (approx.) ........................................................ 5 milliohms
Max Discharge Current (7 Min.) ............................................. 330.0 amperes
Max Short-Duration Discharge Current (10 Sec.) ................ 825.0 amperes
Shelf Life (% of nominal capacity at 68°F (20°C))
1 Month ...................................................................................................... 97%
3 Months ..................................................................................................... 91%
6 Months .................................................................................................... 83%
Operating Temperature Range
Charge .. ........................................................... -4°F (-20°C) to 122°F (50°C)
Discharge ....................................................... -40°F (-40°C) to 140°F (60°C)
Case ...................................................................................................... ABS Plastic
Power-Sonic Chargers ...................................................................................n/a
PS-121100
www.power-sonic.com
To ensure safe and effi cient operation always refer to the latest edition of our Technical Manual, as published on our website.
All data subject to change without notice.
Terminals (mm)
12 Volt 110.0 AH
L:
13.00 (330) W: 6.73 (171) H: 8.35 (212) HT: 8.66 (220)
Features
Absorbent Glass Mat (AGM) technology for superior
performance
Valve regulated, spill proof construction allows safe
operation in any position
Power/volume ratio yielding unrivaled energy density
Rugged impact resistant ABS case and cover (UL94-HB)
Detachable ABS carrying handle
Approved for transport by air. D.O.T., I.A.T.A., F.A.A. and
C.A.B. certifi ed
U.L. recognized under fi le number MH 20845
•
•
•
•
•
•
•
T11 - THREADED
INSERT - 8mm STUD
• T11 - THREADED
INSERT - 8mm STUD
•
