Power-Sonic PG-12v160 User Manual
Pg range, 12yr design life in float service at 20 º c), 5 mω
PG Range
Discharge Characteristics (25ºC, 77ºF)
Physical Specification
Internal Resistance mΩ
Dimensions (mm)
Standard terminal (mm)
Power-Sonic Europe Limited
3 Buckingham Square, Wickford, Essex, SS11 8YQ
Tel: +44 (0)1268 560686 Fax: +44 (0)1268 560902
www.power-sonic.co.uk
PG12V160
Nominal Voltage
Nominal Capacity
12V
160.0 AH
Dimension
Length
Width
Container Height
Total Height (With Terminal)
Weight
Standard Terminal
T11
Approx 47.2kg
485
170
238.5
225
2 mm
2 mm
2 mm
2 mm
+
-
+
-
+
+
-
Rated
Capacity
Capacity
Affected by
Temperature
20hr Rate(1.80V/cell)
10hr Rate(1.80V/cell)
5hr Rate(1.75V/cell)
3hr Rate(1.75V/cell)
1hr Rate(1.60V/cell)
160.6AH
150.0AH
130.5AH
117.0AH
93.0AH
Cycle
Standby
C
o
n
s
ta
n
t
V
o
lt
a
g
e
C
h
a
rg
e
Initial Charging Current
Less than 40.0A
Voltage 14.4V ~ 15.0V
at 25°C (77°F)
Recommended Charge
Current less than 40.0A
Voltage 13.5V ~
13.8V at 15°C (77°F)
40°C (104°F)
25°C (77°F)
0°C (32°F)
103%
100%
86%
3.5 mΩ
Rev3 04/13
2
4
0
2
1
7
0
2
485 2
(12yr Design Life in Float Service at 20ºC)
F.V/Time
10min
15min
20min
30min
45min
1h
2h
3h
4h
5h
6h
8h
10h
20h
1.85V/cell
175.5
147.6
131.0
108.6
83.8
71.7
46.4
34.9
28.6
24.1
21.1
16.9
14.5
7.76
1.80V/cell
200.8
165.7
144.8
118.0
90.4
75.7
49.9
37.5
30.4
25.5
22.3
17.8
15.0
8.03
1.75V/cell
228.1
186.8
160.0
128.2
98.6
82.5
51.9
39.0
31.4
26.1
23.0
18.4
15.4
8.23
1.70V/cell
257.6
207.3
176.6
139.9
106.2
87.3
54.7
41.1
32.9
27.6
24.1
19.2
16.0
8.44
1.65V/cell
276.6
221.9
187.9
147.7
112.4
90.3
56.7
42.7
34.1
28.5
25.0
19.8
16.4
8.70
1.60V/cell
304.3
243.0
204.1
157.6
116.8
93.0
58.1
43.8
34.9
29.2
25.5
20.2
16.8
8.84
F.V/Time
10min
15min
20min
30min
45min
1h
2h
3h
4h
5h
6h
8h
10h
20h
1.85V/cell
327.7
278.4
249.5
209.2
162.8
139.7
91.1
68.7
56.5
47.6
41.9
33.7
29.1
15.5
1.80V/cell
370.6
308.4
271.8
223.7
174.2
146.7
97.3
73.4
59.7
50.3
44.2
35.4
29.9
16.0
1.75V/cell
414.2
343.4
297.5
241.1
188.2
159.2
100.8
76.1
61.6
51.3
45.4
36.5
30.7
16.4
1.70V/cell
457.4
375.7
326.0
261.8
202.0
167.9
105.9
79.9
64.2
54.1
47.5
38.0
31.9
16.8
1.65V/cell
486.7
399.2
344.2
274.1
211.9
172.5
109.2
82.8
66.5
55.7
49.0
39.2
32.7
17.3
1.60V/cell
523.4
430.1
369.9
290.4
219.0
176.7
111. 4
84.5
67.8
56.8
49.9
39.8
33.3
17.6
Constant Current Discharge (Amperes) at 25°C(77°F)
Constant Power Discharge(Watts/cell) at 25°C (77°F)
20
M8
6
Torque 11.0 -14.7 Nm
T11 Threaded Insert 8mm Stud
2
2
5
±
2
In the event of further technical development we reserve the right to alter our design, specification and price without notice. E&O.E
