Charging
Cycle Applications: Limit initial current to 10.5A. Charge until battery voltage
(under charge) reaches 14.4 to 14.7 volts at 68°F (20°C). Hold at 14.4 to 14.7
volts until current drops to under 350mA. Battery is fully charged under these
conditions, and charger should be disconnected or switched to “float” voltage.
“Float” or “Stand-By” Service: Hold battery across constant voltage source of
13.5 to 13.8 volts continuously. When held at this voltage, the battery will seek its
own current level and maintain itself in a fully charged condition.
Note: Due to the self-discharge characteristics of this type of battery, it is
imperative that they be charged within 6 months of storage, otherwise permanent
loss of capacity might occur as a result of sulfation.
Chargers
Power-Sonic offers a wide range of chargers suitable for batteries up to 100AH.
Please refer to the Charger Selection Guide in our specification sheets for “C-Series
Switch Mode Chargers” and “Transformer Type A and F Series”. Please contact our
Technical department for advice if you have difficulty in locating suitable models.
®
Further Information
Please refer to our website www.power-sonic.com for a complete range of useful
downloads, such as product catalogs, material safety data sheets (MSDS), ISO
certification, etc..
Constant Current & Power Discharge Ratings
MODEL
FINAL
VOLTAGE
AMPS/WATTS PER CELL @ 25° C
5 MIN
10 MIN
15 MIN
20 MIN
30 MIN
45 MIN
60 MIN
A
W
A
W
A
W
A
W
A
W
A
W
A
W
PG-12V35 FR
1.80
124
240
84
162
66
128
54
105
42
80
31
60
25
49
1.75
136
260
88
170
70
134
58
109
44
83
33
62
26
50
1.67
148
274
98
182
76
143
62
117
46
86
35
64
27
51
1.60
158
286
106
194
82
150
66
120
50
90
36
66
28
52
Discharge Time vs. Discharge Current
10
9
8
7
6
5
4
3
2
60
50
40
30
20
10
8
6
4
0
1.8
3.6 4.2 5 7.8 11.8 18 36 72 108
Discharge Current (A)
Discharge T
ime
40°C (104°F)
25°C (77°F)
0°C (32°F)
min.
hrs.
C
ap
ac
ity
R
et
en
tion
R
at
io
(%
)
Standing Period (Months)
100
80
60
40
0
0 2 4 6 8 10 12 14 16 18 20
40
o
C
(104
o
F)
30
o
C
(86
o
F)
20
o
C
(68
o
F)
5
o
C
(41
o
F)
Charging is not
necessary unless
100% of capacity
is required.
Charging before
use is necessary
to help recover
full capacity.
Chargemayfail
to restore full
capacity. Do not
let batteries reach
this state.
Discharge Characteristics
Shelf Life & Storage
Discharge Time
Terminal V
oltage (V)
min.
hrs.
13.0
12.0
11.0
10.5
10.0
9.6
9.0
8.0
7.8
20
10
5
3
2
10
5
20
30
3
1.5
0
60
1.8A
3.6A
7.2A
9.0A
18A
36A
72A
108A
Ambient Temperature 25° (77° F)
PG-12V35
FR
12 Volt 36 AH
@ 20-hr. rate
, 35 AH
@ 10-hr. rate
