Power-Sonic PG-12v65 User Manual
Pg range, Pg12v65, 12yr design life in float service at 20 º c)
PG Range
Discharge Characteristics (25ºC, 77ºF)
Physical Specification
Internal Resistance mΩ
Dimensions (mm)
Standard terminal (mm)
Power-Sonic Europe Limited
3 Buckingham Square, Wickford, Essex, SS11 8YQ
Tel: +44 (0)1268 560686 Fax: +44 (0)1268 560902
www.power-sonic.co.uk
PG12V65
Nominal Voltage
Nominal Capacity
12V
65.0 AH
Dimension
Length
Width
Container Height
Total Height (with terminal)
Weight
Standard Terminal
T6
Approx
20
3
. kg
259
168
208
214
2 mm
2 mm
2 mm
2 mm
+
-
+
-
+
+
-
Rated
Capacity
Capacity
Affected by
Temperature
20hr Rate(1.80V/cell)
10hr Rate(1.80V/cell)
8hr Rate(1.75V/cell)
5hr Rate(1.75V/cell)
1hr Rate(1.60V/cell)
65.00AH
63.30AH
62.32AH
58.00AH
47.80AH
Cycle
Standby
C
o
n
s
ta
n
t
V
o
lt
a
g
e
C
h
a
rg
e
Initial Charging Current
Less than 16.25A
Voltage 14.4V ~ 15.0V
at 25°C (77°F)
Recommended Charge
Current less than 16.25A
Voltage 13.5V ~
13.8V at 15°C (77°F)
40°C (104°F)
25°C (77°F)
0°C (32°F)
103%
100%
86%
2
0
8
2
2
1
4
2
1
6
8
2
210
2
259 2
7.4 mΩ
Re
3
v
2
0 /
3
1
(12yr Design Life in Float Service at 20ºC)
16
M6
6
Torque 3.9 ~5.4 Nm
T6 Threaded Insert 6mm Stud
In the event of further technical development we reserve the right to alter our design, specification and price without notice. E&O.E
F.V/Time
5mn
10mn
15mn
20mn
30mn
45mn
1H
2H
3H
4H
5H
6H
7H
8H
9H
10H
20H
1.90V
109.0
87.5
74.6
71.0
56.7
43.8
35.8
19.4
14.0
11.1
9.52
8.29
7.31
6.50
5.95
5.46
2.76
1.85V
139.3
106.7
88.2
82.1
64.0
48.8
40.0
21.8
15.7
12.5
10.60
9.19
8.03
7.23
6.54
6.07
3.09
1.80V
167.7
121.7
98.8
89.4
69.5
52.5
42.5
23.3
16.5
13.3
11.20
9.53
8.41
7.55
6.84
6.33
3.25
1.75V
191.4
131.4
104.1
92.7
72.0
54.0
43.8
24.0
17.0
13.7
11.60
10.00
8.71
7.79
7.07
6.55
1.70V
217.0
142.0
110.3
96.4
73.4
55.5
45.0
24.5
17.3
14.0
11.90
10.10
8.88
7.94
7.20
6.67
1.65V
239.7
149.1
114.7
100.2
74.9
56.5
46.4
25.0
17.7
14.3
12.10
10.30
9.02
8.06
7.31
6.77
1.60V
248.3
154.4
119.1
104.0
78.3
58.3
47.8
25.7
18.1
14.5
12.30
10.50
9.17
8.20
7.44
6.89
F.V/Time
5mn
10mn
15mn
20mn
30mn
45mn
1H
2H
3H
4H
5H
6H
7H
8H
9H
10H
20H
1.90V
214.2
173.4
148.7
142.5
114.5
88.8
72.9
39.6
28.7
22.7
19.6
17.1
15.1
13.4
12.3
11.3
5.71
1.85V
267.4
206.9
172.7
162.3
127.9
98.4
81.2
44.4
32.1
25.6
21.8
18.9
16.6
15.0
13.5
12.5
6.38
1.80V
316.8
232.0
189.9
173.3
136.2
104.1
85.1
46.9
33.3
27.0
22.8
19.5
17.2
15.5
14.0
13.1
6.70
1.75V
354.0
246.5
197.7
178.0
139.9
106.5
87.3
48.2
34.2
27.7
23.5
20.3
17.8
16.0
14.5
13.5
1.70V
390.4
260.5
206.6
183.8
141.8
109.0
89.4
49.0
34.8
28.3
24.1
20.6
18.1
16.2
14.8
13.7
1.65V
425.3
271.0
213.2
189.6
143.5
110.0
91.5
49.7
35.4
28.8
24.5
20.9
18.3
16.5
15.0
13.9
1.60V
430.5
274.4
217.8
194.7
149.0
112.9
93.8
50.9
36.1
29.1
24.8
21.2
18.6
16.7
15.3
14.2
Constant Current Discharge Characteristics Unit: Amperes
(25ºC, 77ºF)
Constant Power Discharge Characteristics Unit: (Watts/cell)
(25ºC, 77ºF)
