Power-Sonic PSX12-13 User Manual
Psx series, Vrla 6yr design life at 20 ) ºc

PSX Series
Designed for UPS Applications
Discharge Characteristics (25ºC, 77ºF)
Physical Specification
Internal Resistance mΩ
Dimensions (mm)
Standard terminal (mm)
PSX12-13 12V 13AH
Nominal Voltage
Nominal Capacity
12V
13 AH
Dimension
Length
Width
Container Height
Total Height (with terminal)
Weight
Standard Terminal
F2
Approx 4.2kg
151
98
95
101
2 mm
2 mm
2 mm
2 mm
+
-
+
-
+
+
-
Capacity
Affected by
Temperature
Standby
C
ons
tant
V
o
lta
ge
C
ha
rge
Recommended Charge
Current less than 3.25A
Voltage 13.5V ~
13.8V at 25°C (77°F)
40°C (104°F)
25°C (77°F)
0°C (32°F)
103%
100%
86%
6.35
7.95
3.4
0.8
F2
Approx 14.0 mΩ
Power-Sonic Europe Limited
3 Buckingham Square, Wickford, Essex, SS11 8YQ
Tel: +44 (0)1268 560686 Fax: +44 (0)1268 560902
www.power-sonic.co.uk
Rev3 02/13
-
(VRLA 6yr Design Life at 20
)
ºC
98
2
151
2
80
2
101
2
+
-
Power
Rating
3hr to(1.67V/cell)
1hr to(1.67V/cell)
15min to(1.67V/cell)
39.06 Watts
96.06 Watts
298.56 Watts
Constant Power Discharge Characteristics Unit: W atts / Cell (25ºC, 77ºF)
Constant Current Discharge Characteristics Unit: Amperes (25ºC, 77ºF)
In the event of further technical development we reserve the right to alter our design, specification and price without notice. E&O.E
F.V(V/cell)
15min
1H
3H
1.85
20.56
7.11
2.87
1.80
22.50
7.59
3.03
1.75
24.64
7.94
3.15
1.70
26.29
8.19
3.27
1.67
27.94
8.47
3.38
1.60
29.39
8.77
3.48
F.V(V/cell)
15min
1H
3H
1.85
38.32
13.68
5.63
1.80
41.52
14.55
5.90
1.75
44.81
15.13
6.11
1.70
47.14
15.62
6.33
1.67
49.76
16.01
6.51
1.60
51.31
16.49
6.67
95
2
