Power-Sonic PS-1-3AAH - Manual

Sealed Nickel Cadmium Batteries High Temperature Model: PS-1/3AAH
Specifications Dimensions
Nominal Voltage 1.2 Volt
Rated Capacity 110 mAh
Dimensions
Diameter in. (mm) 0.56 (14.1)
Height in. (mm) 0.67 (17.0)
Height with solder tabs 0.71 (18.0)
Weight Approx. 7 gm
Internal Resistance <15 mΩ
Standard Charge (0.1C) 11 mA
Trickle Charge (0.03C)~(0.05C)
Fast Charge ΔV 110 mA
Recommended Std/Trickle Charge 0 to 70°C
Operating Fast Charge 0 to 70°C
Temperature Discharge -20 to 70°C
Range Storage -20°C to 60°C
Standard Discharge (0.2C) Cut Off Voltage 1.0V per cell
High Rate Discharge (1 C) Cut Off Voltage 1.0V per cell
Charging and Discharging Characteristics
Discharge Standard Charge
Fast Charge Trickle Charge
in. (mm)
We’ve Got The Power.™
All data subject to change without notice
