Power-Sonic PSX12-2.5 User Manual

Psx series, Vrla 6yr design life at 20°c)

background image

PSX Series

Designed for UPS Applications

Discharge Characteristics (25ºC, 77ºF)

Physical Specification

Internal Resistance mΩ

Dimensions (mm)

Standard terminal (mm)

Constant Power Discharge Characteristics Unit: Watts / Cell (25ºC, 77ºF)

Constant Current Discharge Characteristics Unit: Amperes (25ºC, 77ºF)

PSX12-2.5 12V 2.5AH

Nominal Voltage

Nominal Capacity (20HR)

12V

2.5 AH

Dimension

Length

Width

Container Height

Total Height (with terminal)

Weight

Standard Terminal

F1

Approx 1.0kg

178

35

60

66

2 mm

2 mm

2 mm

2 mm

+

-

+

-

+

+

-

Power

Rating

Capacity

Affected by

Temperature

3hr Rate(1.67V/cell)

1hr Rate(1.67V/cell)

15min Rate(1.67V/cell)

7.16 Watts

17.28 Watts

45.90 Watts

Standby

Const

a

n

t

V

olta

ge

C

h

a

rge

Recommended Charge
Current less than 0.62A
Voltage 13.5V ~
13.8V at 25°C (77°F)

40°C (104°F)

25°C (77°F)

0°C (32°F)

103%

100%

86%

4.75

6.35

3.2

0.8

F1

+

-

35

2

178

2

60

2

66

2

Approx 70.0 mΩ

Power-Sonic Europe Limited

3 Buckingham Square, Wickford, Essex, SS11 8YQ

Tel: +44 (0)1268 560686 Fax: +44 (0)1268 560902

[email protected]

www.power-sonic.co.uk

Rev3 - 02/13

-

(VRLA 6yr Design Life at 20°C)

In the event of further technical development we reserve the right to alter our design, specification and price without notice. E&O.E

F.V(V/cell)

15min

1H

3H

1.85

3.15

1.29

0.527

1.80

3.46

1.37

0.567

1.75

3.78

1.43

0.577

1.70

4.04

1.47

0.594

1.67

4.30

1.53

0.619

1.60

4.51

1.58

0.638

F.V(V/cell)

15min

1H

3H

1.85

5.89

2.50

1.028

1.80

6.38

2.62

1.106

1.75

6.89

2.73

1.116

1.70

7.25

2.81

1.154

1.67

7.65

2.88

1.193

1.60

7.90

2.97

1.222
