Power-Sonic PG-2v1100 User Manual
Pg range, 15yr design life in float service at 20 º c)
PG Range
Discharge Characteristics (25ºC, 77ºF)
Physical Specification
Internal Resistance mÙ
Dimensions (mm)
Standard terminal (mm)
Power-Sonic Europe Limited
3 Buckingham Square, Wickford, Essex, SS11 8YQ
Tel: +44 (0)1268 560686 Fax: +44 (0)1268 560902
www.power-sonic.co.uk
PG-2V1100
Nominal Voltage
Nominal Capacity
2V
1060 AH
Dimension
Length
Width
Container Height
Total Height (with terminal)
Weight
Standard Terminal
T11
Approx 66.0kg
475
175
328
350
3 mm
3 mm
3 mm
3 mm
+
-
+
-
+
+
-
Rated
Capacity
Capacity
Affected by
Temperature
Cycle
Standby
C
o
n
s
ta
n
t
V
o
lt
a
g
e
C
h
a
rg
e
Initial Charging Current
Less than 275A
Voltage 2.4V ~ 2.5V
at 25°C (77°F)
Recommended Charge
Current less than 275A
Voltage 2.25V ~ 2.3V
at 25°C (77°F)
40°C (104°F)
25°C (77°F)
0°C (32°F)
103%
100%
86%
Rev4 10/12
3
3
5
3
3
2
8
3
475
3
1
7
5
3
3
5
0
3
Approx 0.45mÙ
(15yr Design Life in Float Service at 20ºC)
In the event of further technical development we reserve the right to alter our design, specification and price without notice. E&O.E
20hRate(
) 1060.00AH
1.80V/cell
10hRate(
) 1000.00AH
1.80V/cell
8hRate(
) 971.20AH
1.75V/cell
5hRate(
) 862.50AH
1.75V/cell
1hRate(
) 605.00AH
1.60V/cell
F.V/Time
15min
20min
30min
45min
1h
2h
3h
4h
5h
8h
10h
20h
1.85V/cell
943.8
836.4
696.3
550.8
460.6
303.3
229.9
186.8
158.5
112.2
96.2
51.2
1.80V/cell
1067.3
930.9
760.5
593.3
488.3
322.6
242.7
195.9
166.5
117.9
100.0
53.0
1.75V/cell
1205.2
1030.1
826.8
640.0
529.0
338.8
255.0
204.7
172.5
121.4
102.3
54.0
1.70V/cell
1334.6
1135.0
900.6
674.7
559.9
357.3
267.3
213.5
179.9
125.9
105.6
55.3
1.65V/cell
1424.6
1203.7
947.1
720.0
580.4
369.7
277.0
221.0
186.3
129.2
107.9
56.6
1.60V/cell
1580.1
1324.2
1022.8
750.7
605.0
383.5
286.3
228.0
192.9
132.7
110.8
57.9
Constant Current Discharge (Amperes) at 25 °C (77°F )
F.V/Time
15min
20min
30min
45min
1h
2h
3h
4h
5h
8h
10h
20h
1.85V/cell
1769.6
1584.2
1333.3
1063.7
892.6
591.6
450.1
367.0
312.2
222.4
191.1
101.8
1.80V/cell
1974.5
1737.3
1434.1
1136.9
941.3
625.2
472.5
382.8
326.4
232.9
198.3
105.3
1.75V/cell
2202.2
1904.2
1546.3
1214.7
1015.1
654.1
494.6
398.5
337.0
239.3
202.7
107.2
1.70V/cell
2405.0
2082.4
1675.1
1275.8
1070.9
688.3
517.6
414.9
350.9
247.8
208.8
109.5
1.65V/cell
2547.5
2192.0
1747.3
1349.3
1102.2
708.2
534.0
427.8
362.1
253.7
213.0
112.0
1.60V/cell
2779.0
2385.2
1873.8
1399.2
1142.8
731.1
549.5
440.0
373.6
260.1
218.4
114.5
Constant Power Discharge (Watts/cell) at 25°C (77°F )
20
M8
6
Torque 11.0 -14.7 Nm
T11 Threaded Insert 8mm Stud
