Power-Sonic PS-12700V0 User Manual
Vo series, 10yr design life in float service at 20 º c)

VO Series
Discharge Characteristics (25ºC, 77ºF)
Physical Specification
Internal Resistance mΩ
Dimensions (mm)
Standard terminal (mm)
Power-Sonic Europe Limited
3 Buckingham Square, Wickford, Essex, SS11 8YQ
Tel: +44 (0)1268 560686 Fax: +44 (0)1268 560902
www.power-sonic.co.uk
PS-12700 VO
Nominal Voltage
Nominal Capacity (20HR)
12V
70.0 AH
Dimension
Length
Width
Container Height
Weight
Standard Terminal
T6
Approx 21.6kg
348
167
178
2 mm
2 mm
2 mm
+
-
+
+
-
Rated
Capacity
Capacity
Affected by
Temperature
72.80AH
70.00AH
66.72AH
60.00AH
42.70AH
Cycle
Standby
C
o
n
s
ta
n
t
V
o
lt
a
g
e
C
h
a
rg
e
Initial Charging Current
Less than 17.5A
Voltage 14.40V ~ 15.0V
at 25°C (77°F)
Recommended Charge
Current less than 17.5A
Voltage 13.5V ~
13.8V at 25°C (77°F)
40°C (104°F)
25°C (77°F)
0°C (32°F)
103%
100%
86%
Rev2 03/12
1
7
8
2
1
4
3
2
1
6
4
2
167 2
348 2
262 2
6.6mΩ
(10yr Design Life in Float Service at 20ºC)
In the event of further technical development we reserve the right to alter our design, specification and price without notice. E&O.E
20hr Rate (1.80V/cell)
10hr Rate (1.80V/cell)
8hr Rate (1.75V/cell)
5hr Rate (1.75V/cell)
1hr Rate (1.60V/cell)
16
M6
6
Torque 3.9 ~5.4 Nm
T6 Threaded Insert 6mm Stud
F.V/Time
5min
10m in
15m in
20min
30min
45min
1h
2h
3h
4h
5h
6h
8h
10h
20h
1.85V/cell
119.8
94.2
80.1
67.0
53.2
40.3
33.0
21.0
16.6
13.6
10.9
9.53
7.74
6.61
3.61
1.80V/cell
160.8
120.4
96.8
79.2
62.8
46.9
37.0
22.9
17.9
14.5
11.7
10.2
8.20
7.00
3.64
1.75V/cell
181.3
132.2
105.7
85.2
65.2
48.6
38.7
23.8
18.2
14.8
12.0
10.5
8.34
7.07
3.68
1.70V/cell
199.7
144.1
112.9
89.5
67.9
50.6
39.9
24.7
18.7
15.2
12.4
10.7
8.46
7.14
3.75
1.65V/cell
220.2
155.6
120.0
95.1
71.6
51.8
41.2
25.4
19.5
15.7
12.7
11.0
8.60
7.29
3.79
1.60V/cell
242.8
168.9
128.3
101.3
75.6
54.0
42.7
26.3
20.1
16.2
13.1
11.2
8.68
7.36
3.82
F.V/Time
5min
10m in
15m in
20min
30min
45min
1h
2h
3h
4h
5h
6h
8h
10h
20h
1.85V/cell
219.1
174.0
149.5
126.3
101.5
77.5
63.6
40.8
32.4
26.5
21.4
18.7
15.3
13.0
7.14
1.80V/cell
290.9
219.7
178.2
147.1
117.9
89.4
70.9
44.2
34.7
28.2
22.9
20.0
16.1
13.8
7.20
1.75V/cell
321.0
237.5
192.2
156.7
121.4
91.9
73.9
45.7
35.2
28.7
23.5
20.5
16.4
13.9
7.26
1.70V/cell
343.7
253.0
202.4
163.5
125.7
95.2
75.9
47.4
36.1
29.4
24.0
20.9
16.6
14.1
7.39
1.65V/cell
373.6
270.6
213.5
172.4
131.5
96.7
77.9
48.5
37.4
30.3
24.6
21.3
16.8
14.3
7.48
1.60V/cell
402.6
287.1
224.6
181.6
137.8
100.2
80.3
49.9
38.4
31.2
25.3
21.7
17.0
14.5
7.51
Constant Current Discharge (Amperes) at 25°C(77°F)
Constant Power Discharge (Watts) at 25°C(77°F)
