PG Range

Discharge Characteristics (25ºC, 77ºF)

Physical Specification

Internal Resistance mΩ

Dimensions (mm)

Standard terminal (mm)

Power-Sonic Europe Limited

3 Buckingham Square, Wickford, Essex, SS11 8YQ

Tel: +44 (0)1268 560686 Fax: +44 (0)1268 560902

[email protected]

www.power-sonic.co.uk

PG-2V110

Nominal Voltage

Nominal Capacity

2V

107 AH

Dimension

Length

Width

Container Height

Total Height (with terminal)

Weight

Standard Terminal

T6

Approx 6.0kg

170

72

205

212

2 mm

2 mm

2 mm

2 mm

+

-

+

-

+

+

-

Rated

Capacity

Capacity

Affected by

Temperature

Cycle

Standby

C

o

n

s

ta

n

t

V

o

lt

a

g

e

C

h

a

rg

e

Initial Charging Current
Less than 27.5A
Voltage 14.4V ~ 15.0V
at 25°C (77°F)

Recommended Charge
Current less than 27.5A
Voltage 13.5V ~
13.8V at 15°C (77°F)

40°C (104°F)

25°C (77°F)

0°C (32°F)

103%

100%

86%

Rev5 02/12

2

1

2

2

2

0

5

2

170

2

7

2

2

1.4mΩ

16

M6

6

T6 Threaded Insert 6mm STUD

(15yr Design Life in Float Service at 20ºC)

In the event of further technical development we reserve the right to alter our design, specification and price without notice. E&O.E

20hRate(1.80V/cell) 107.00AH
10hRate(1.80V/cell) 100.00AH

5hRate(1.75V/cell) 87.00AH
3hRate(1.75V/cell) 78.00AH
1hRate(1.60V/cell) 62.00AH

F.V/Time

10min

15min

20min

30min

45min

1h

2h

3h

4h

5h

6h

8h

10h

20h

1.85V/cell

117.00

98.40

87.30

72.40

55.90

47.80

31.00

23.30

19.10

16.00

14.10

11.30

9.69

5.17

1.80V/cell

133.90

110.50

96.50

78.60

60.30

50.50

33.30

25.00

20.30

17.00

14.90

11.90

10.00

5.35

1.75V/cell

152.10

124.50

106.70

85.50

65.70

55.00

34.60

26.00

21.00

17.40

15.40

12.30

10.30

5.49

1.70V/cell

171.70

138.20

117.70

93.30

70.80

58.20

36.50

27.40

21.90

18.40

16.10

12.80

10.70

5.63

1.65V/cell

184.40

147.90

125.30

98.50

74.90

60.20

37.80

28.50

22.80

19.00

16.70

13.20

11.00

5.80

1.60V/cell

202.90

162.00

136.10

105.10

77.90

62.00

38.80

29.20

23.30

19.40

17.00

13.40

11.20

5.89

Constant Current Discharge (Amperes) at 25 °C (77°F )

F.V/Time

10min

15min

20min

30min

45min

1h

2h

3h

4h

5h

6h

8h

10h

20h

1.85V/cell

218.50

185.60

166.30

139.40

108.50

93.20

60.70

45.80

37.70

31.80

27.90

22.50

19.40

10.30

1.80V/cell

247.10

205.60

181.20

149.20

116.10

97.80

64.80

49.00

39.80

33.50

29.40

23.60

20.00

10.70

1.75V/cell

276.20

228.90

198.30

160.80

125.50

106.10

67.20

50.70

41.00

34.20

30.30

24.30

20.50

10.90

1.70V/cell

304.90

250.50

217.30

174.60

134.70

112.00

70.60

53.30

42.80

36.10

31.70

25.30

21.20

11.20

1.65V/cell

324.50

266.20

229.50

182.70

141.20

115.00

72.80

55.20

44.30

37.10

32.70

26.10

21.80

11.60

1.60V/cell

348.90

286.80

246.60

193.60

146.00

117.80

74.30

56.40

45.20

37.90

33.30

26.50

22.20

11.70

Constant Power Discharge (Watts/cell) at 25°C (77°F )
