Sealed Nickel-Metal Hydride Rechargeable Batteries Model:NH-8000D
Specifications Dimensions
Nominal Voltage 1.2 Volt
Rated Capacity 8000 mAh
Dimensions
Diameter in. (mm) 1.27 (32.2)
Height in. (mm) 2.32 (59.0)
Height with solder tabs 2.36 (60.0)
Weight Approx. 160 gm
Internal Resistance <9 mΩ
Standard Charge (0.1C) 800 mA
Trickle Charge (0.03C)~(0.05C)
Fast Charge ΔV 4000 mA
Recommended Std/Trickle Charge 20±5°C
Operating Fast Charge 20±5°C
Temperature Discharge 20±5°C
Range Storage -20°C to 45°C
Standard Discharge (0.2C) Cut Off Voltage 1.0V per cell
High Rate Discharge (1 C) Cut Off Voltage 1.0V per cell
Charging and Discharging Characteristics
Discharge Cycle Life Standard Charge
Standard Battery Discharging (0.2C/0.5C/1C Standard Battery Discharging (1C/2C/3C)
in. (mm)
