Power-Sonic NH-B320 User Manual
Power-Sonic For the car
Sealed Nickel-Metal Hydride Rechargeable Batteries
Model:NH-B320
Specifications
Dimensions
Nominal Voltage
1.2 Volt
Rated Capacity
32 mAh
Dimensions
Diameter in. (mm)
0.98 (25.0)
Height in. (mm)
0.30 (7.6)
Height with solder tabs
0.34 (8.6)
Weight Approx.
14.5 gm
Internal Resistance
<1200 mΩ
Standard Charge (0.1C)
32 mA
Trickle Charge
(0.03C)~(0.05C)
Fast Charge ΔV
n/a
Recommended Std/Trickle Charge
20±5°C
Operating
Fast Charge
20±5°C
Temperature
Discharge
20±5°C
Range
Storage
-20°C to 45°C
Standard Discharge (0.2C) Cut Off Voltage
1.0V per cell
High Rate Discharge (1 C) Cut Off Voltage
1.0V per cell
Charging and Discharging Characteristics
Discharge Cycle Life
Standard Charge
Standard Battery Discharging (0.2C/0.5C/1C
Standard Battery Discharging (1C/2C/3C)
in. (mm)
We’ve Got The Power.™
All data subject to change without notice
