Power-Sonic PSX12-45 User Manual
Psx series, Vrla 10yr design life at 20 ) ºc
PSX Series
Designed for UPS Applications
Discharge Characteristics (25ºC, 77ºF)
Physical Specification
Internal Resistance mΩ
Dimensions (mm)
Standard terminal (mm)
PSX12-45 12V 45AH
Nominal Voltage
Nominal Capacity
12V
45 AH
Dimension
Length
Width
Total Height
Height to top of terminal
Weight
Standard Terminal
T6
Approx 13.2kg
197
165
170
156
2 mm
2 mm
2 mm
2 mm
+
-
+
-
+
+
-
Capacity
Affected by
Temperature
Standby
C
on
s
tant
V
o
lta
g
e
Ch
ar
ge
Recommended Charge
Current less than 10.0A
Voltage 13.5V ~
13.8V at 25°C (77°F)
40°C (104°F)
25°C (77°F)
0°C (32°F)
103%
100%
86%
Approx 10.0 mΩ
Power-Sonic Europe Limited
3 Buckingham Square, Wickford, Essex, SS11 8YQ
Tel: +44 (0)1268 560686 Fax: +44 (0)1268 560902
www.power-sonic.co.uk
Rev3 02/13
-
(VRLA 10yr Design Life at 20
)
ºC
156
2
143
2
158
165
2
170
2
197
2
2
Power
Rating
3hr to(1.67V/cell)
1hr to(1.67V/cell)
15min to(1.67V/cell)
123.36 Watts
277.02 Watts
757.74 Watts
Constant Power Discharge Characteristics Unit: W atts / Cell (25ºC, 77ºF)
Constant Current Discharge Characteristics Unit: Amperes (25ºC, 77ºF)
In the event of further technical development we reserve the right to alter our design, specification and price without notice. E&O.E
F.V(V/cell)
15min
1H
3H
1.85
48.79
20.18
9.35
1.80
57.23
21.92
9.80
1.75
62.57
22.89
9.99
1.70
66.74
23.67
10.19
1.67
71.00
24.44
10.67
1.60
75.95
25.32
10.96
F.V(V/cell)
15min
1H
3H
1.85
91.08
38.80
18.33
1.80
105.34
42.00
19.01
1.75
113.68
43.75
19.30
1.70
119.70
45.01
19.79
1.67
126.29
46.17
20.56
1.60
132.79
47.53
21.15
16
M6
6
Torque 3.9 ~5.4 Nm
T6 Threaded Insert 6mm Stud
