Power-Sonic PS-682 User Manual
Ps range, 5yr design life in float service at 20c) º, Dimensions (mm) standard terminal (mm)

PS Range
Discharge Characteristics (25ºC, 77ºF)
Physical Specification
Internal Resistance m
Ω
Dimensions (mm)
Standard terminal (mm)
Power-Sonic Europe Limited
3 Buckingham Square, Wickford, Essex, SS11 8YQ
Tel: +44 (0)1268 560686 Fax: +44 (0)1268 560902
www.power-sonic.co.uk
PS-682 6V 8.0AH
Nominal Voltage
Nominal Capacity (20HR)
6V
8.0 AH
Dimension
Length
Width
Container Height
Total Height (with terminal)
Weight
Standard Terminal
F1
Approx 1.52kg
98
56
118
120
2 mm
2 mm
2 mm
2 mm
+
-
+
-
+
+
-
Rated
Capacity
Capacity
Affected by
Temperature
Cycle
Standby
C
o
n
s
ta
n
t
V
o
lt
a
g
e
C
h
a
rg
e
Initial Charging Current
Less than 2.0A
Voltage 7.20V ~ 7.50V
at 25°C (77°F)
Recommended Charge
Current less than 2.0A
Voltage 6.75V ~
6.90V at 25°C (77°F)
40°C (104°F)
25°C (77°F)
0°C (32°F)
103%
100%
86%
4.75
6.35
3.2
0.8
F1
Rev4 04/13
2
98 2
1
1
8
2
1
2
0
56 2
14.5m
Ω
-
(5yr Design Life in Float Service at 20C)
º
In the event of further technical development we reserve the right to alter our design, specification and price without notice. E&O.E
F.V/Time
5min
10min
15min
20min
30min
45min
1h
2h
3h
4h
5h
6h
8h
10h
20h
1.85V/cell
16.2
12.4
10.3
8.90
6.88
5.07
4.27
2.53
1.98
1.61
1.31
1.14
0.918
0.767
0.421
1.80V/cell
21.7
15.9
12.4
10.5
8.12
5.90
4.79
2.76
2.13
1.72
1.41
1.22
0.973
0.791
0.425
1.75V/cell
24.5
17.5
13.6
11.3
8.43
6.12
5.01
2.86
2.17
1.76
1.45
1.25
0.990
0.812
0.429
1.70V/cell
27.0
19.0
14.5
11.9
8.78
6.36
5.17
2.93
2.23
1.80
1.48
1.28
1.004
0.828
0.437
1.65V/cell
29.7
20.5
15.4
12.6
9.26
6.52
5.29
2.98
2.32
1.86
1.52
1.31
1.020
0.845
0.443
1.60V/cell
32.8
22.3
16.5
13.5
9.78
6.80
5.34
3.10
2.39
1.92
1.57
1.34
1.030
0.854
0.445
Constant Current Discharge (Amperes) at 25 °C (77°F )
F.V/Time
5min
10min
15min
20min
30min
45min
1h
2h
3h
4h
5h
6h
8h
10h
20h
1.85V/cell
29.6
23.0
19.2
16.8
13.1
9.75
8.25
4.91
3.86
3.14
2.57
2.24
1.81
1.52
0.834
1.80V/cell
39.3
29.0
22.9
19.5
15.2
11.2
9.19
5.32
4.13
3.34
2.75
2.39
1.92
1.56
0.841
1.75V/cell
43.4
31.3
24.7
20.8
15.7
11.6
9.57
5.50
4.18
3.40
2.81
2.45
1.94
1.60
0.848
1.70V/cell
46.4
33.4
26.0
21.7
16.2
12.0
9.84
5.62
4.29
3.49
2.88
2.49
1.97
1.63
0.863
1.65V/cell
50.5
35.7
27.4
22.9
17.0
12.2
9.99
5.67
4.46
3.59
2.95
2.54
2.00
1.66
0.873
1.60V/cell
54.4
37.9
28.9
24.1
17.8
12.6
10.0
5.89
4.57
3.69
3.03
2.59
2.01
1.68
0.877
Constant Power Discharge (Watts/cell) at 25°C (77°F )
20hRate(1.80V/cell) 8.50AH
10hRate(1.80V/cell) 7.91AH
5hRate(1.75V/cell) 7.25AH
3hRate(1.75V/cell) 6.51AH
1hRate(1.65V/cell) 5.34AH
