EN-20 5000 Series Indicators
Reset No, Yes
Range Single, Dual
Full Scale Capacity 1…999950
Graduation 0.00001…1000
Power On unit Auto, kg, g, lb, oz, lb:oz
Zero Range 2%, 100%
Auto-Tare Off, On, Accept
Retain Weight Data Off, On
Legal for Trade Off, On
Beeper Volume Off, Lo, Hi
Beeper Signal Off, Accept, Under, Over, Under- Over
Button Beep Off, On
End Setup Exit SETUP menu
3.4 Setup Menu
When the Indicator is used for the first time, enter this
menu to set the Range, Capacity and Graduation. Default
settings are
bold.
3.4.1 Reset
Reset the Setup menu to the factory defaults. (except Range, Capacity and Graduation)
NO
= not reset.
YES = reset.
NOTE: If the Legal for Trade menu item is set to ON, the Range, Capacity, Graduation, Zero Range, Auto Tare,
Retain Weight Data and Legal For Trade settings are not reset.
3.4.2 Range
Set the number of weighing ranges.
SINGLE = one weighing range from zero to full capacity.
dUAL = two weighing ranges, where range 1 is from zero to half capacity and range 2 is from
half capacity to full capacity.
3.4.3 Capacity
Set the scale capacity as explained in Section 3.2 Menu Navigation.
NOTE: If dUAL was selected in the rANGE menu item, the Capacity setting defines the Range 2 capacity. The
Range 1 capacity is automatically defined as half of the Capacity setting. For example, if Capacity is set to
15, the Range 1 capacity becomes 7.5.
After the capacity is set, select the Primary Unit.
kg = the primary unit is kilograms
lb
= the primary unit is pounds
