EN-14 3000 Series Indicators
3.2 Menu Navigation
3.3 Calibration Menu
Two calibration processes are available: Span Calibration and Linearity
Calibration.
Span Perform
Linearity Perform
Geographic
Adjustment 0…31
End Calibration Exit CALIBRATION menu
NOTES:
1. Make sure that appropriate calibration masses are available before
beginning calibration.
2. Make sure that the scale base is level and stable during the entire
calibration process.
3. Calibration is unavailable with LFT set to On.
4. Allow the Indicator to warm up for approximately 5 minutes after
stabilizing to room temperature.
5. To abort calibration, press the Exit button anytime during the calibration
process.
TO ENTER THE MENU MODE
Press and hold the Menu button until MENU appears on the display. The first upper level menu appears on
the display.
Summary of button navigation functions in menu mode:
Yes Allows entry into the displayed menu.
Accepts the displayed setting and advances to the next menu item.
No Skips by the displayed menu.
Rejects the displayed setting or menu item and advances to the next available item.
Back Moves backwards through the upper and middle level menus.
Backs out of a list of selectable items to the previous middle level menu.
Exit Exits from menu directly to the active weighing mode.
For Checkweigh under and over targets setup, the current setting is displayed with all digits flashing. Press
the No button to begin editing.
The first digit is displayed flashing.
Press the No button to increment the digit or press the Yes button to accept the digit and move to the next
digit.
Repeat this process for all digits.
Press the Yes button when the last digit has been set.
The new setting is displayed with all digits flashing. Press the Yes button to accept the setting or press the
No button to resume editing.
