Power Module
Pin
1
2
3
4
A
B
C
D
E
F
G
H
J
K
L
M
N
P
R
S
Color
Red
Black
Orange
Red
Red
Blue
Bro/Wht
Brown
Lt Blue
Gray
Red
Orange
Red
Red
Yellow
Blk/Wht
Blk/Red
Green
Black
Lt Green
Use
REQ
REQ
REQ
REQ
OPT
OPT
OPT
OPT
OPT
OPT
REQ
OPT
REQ
REQ
REQ
REQ
REQ
REQ
REQ
OPT
Function
Battery 1, Connect to Positive Battery terminal.
Ground, Connect to solid, clean engine ground.
Pump, Connect to Fuel Pump Positive terminal.
Battery 2, Connect to Battery Positive terminal.
Fan 1, Supplies ground to activate Fan 1
Launch, Connect to 12 volts to activate 2-step RPM limit.
Nitrous, When supplied with 12 volts, timing will be retarded and
the air/fuel ratio will be corrected to the target nitrous setting.
Speed Ref.
Speed Signal
Tach, Supplies 12V square wave signal
Switched 12V, Connect to ignition switch
Fan 2, Supplies ground to activate Fan 2 at desired temperature.
Supplies power to the Fuel Rail
IP
VM
H-
H+
IA
UN
WBO2
MIL Ground
CONNECTOR
Deutsch 4-
W
ay
CONNECTOR
G
T Series 16 W
ay
STOP HERE
REVIEW YOUR INSTALLATION
It is recommended to review your installation at this point. The 02 Sensor should be installed and connected
as well as the Power Module and corresponding wiring. Confirm that all of the rail wiring connections are
complete including the injectors and sensors. Ensure all fuel lines and fittings are tight and secure from
any heat sources or sharp edges. The next section will require powering the Atomic LS to go through
the Initial Setup menus and the fuel pump will run. DO NOT START THE ENGINE AT THIS TIME!
It is recommended to connect a Malfunction
Indicator Lamp (MIL) to your dash. A simple
bulb is required with switched 12 volts on
one side and this Light Green wire on the
ground side. If there is a malfunction in the
system, ground will be supplied through this
wire to illuminate the lamp.
