DEFAULT MENU
Notes: 7530TV1. Uses menu 7530M01
MSD Digital Race Ignition.
Factory default data and menu.
7530T MO1
Monitor
Stats
Stat 1
RevLim
RevBurn
*Rpm 7000
RevMax
RevMax
*OutCAM
*Rpm 9500
*AdjOFF
RevLaun
RevLaunch
*Rpm 6200
TimeRev
TimeRev
Time 9.0
Rpm 2000
Retards
Start
StartRetard
* Deg10
Launch
LaunchRetard
* Deg .0
* Ramp .50
Step1
* Rpm 800
* On .00
* Off .00
* Deg 2.0
Step2
* Rpm 800
* On .00
* Off .00
* Deg 3.0
Step 3
* Rpm 800
* On .00
* Off .00
* Deg 5.0
StepDly
Step Retards
* OffDelay .50Sec
Gear 1
Pt 1
Rpm 800
Gear1
Deg .0
Gear2
Pt 1
Rpm 800
Gear2
Deg .0
Gear3
Pt 1
Rpm 800
Gear3
Deg .0
Gear4
Pt 1
Rpm 800
Gear 4
Deg .0
Gear5
Pt 1
Rpm 800
Gear5
Deg .0
Gear6
Pt 1
Rpm 800
Gear6
Deg .0
Advance
Gear1
* (1) dRpm 600
* (2) dRpm 600
* (3) dRpm 600
* (4) dRpm 600
* (5) dRpm 600
* (1) Deg .0
* (2) Deg .0
* (3) Deg .0
* (4) Deg .0
* (5) Deg .0
* (1) Sec .00
* (2) Sec .00
* (3) Sec .00
* (4) Sec .00
* (5) Sec .00
CylCnt
*CylCnt 8
*TachTrigger
DylDeg
SparkSEQ1
* (1) Cyl1
* (2) Cyl2
* (3) Cyl3
* (4) Cyl4
* (5) Cyl5
* (6) Cyl6
* (7) Cyl7
* (8) Cyl8
* (1) Deg .0
* (2) Deg .0
* (3) Deg .0
* (4) Deg .0
* (5) Deg .0
* (6) Deg .0
* (7) Deg .0
* (8) Deg .0
* SeqUser
RpmTimeSw
* SwSel RPM
RpmSw
*RpmOn 2000
*RpmOff 6000
TimeSw
*OnDelay 1.00
*OnTime 2.00
Shift
LaunchLight
*RpmHi 3200
*RpmLo 2800
ShiftLights
ShiftLight1
* (1) Rpm12500
* (2) Rpm12300
* (3) Rpm 12100
* (4) Rpm11900
* (5) Rpm11700
Gears
ShiftGr
Gear1
* (1) DropRpm 600
* (2) DropRpm 600
* (3) DropRpm 600
* (4) DropRpm 600
* (5) DropRpm 600
LastGr
*LastGear5
SetGear
StepWire 123
*SetGearOFF
Alerts
Alert 1
(1) SCAN
(2) SCAN
Fault
*BrownOut 0
*WatchDog 0
AlertsPer
*Alerts/Scan 0
