High Lifter Lift Kit for Can-Am 1000 Outlander and Renegade 1000 - Signature Series - Manual (Page 11)

11
10) Connect the new sway bar brackets to the sway bar and rear arms. Use two 10x60 hex bolts and 10mm lock
nuts to secure the bracket.
11) Insert the rear lift bracket that has the ear on it into the shock mount tab.
12) Insert the rear spacer into the shock mount tab next to the bracket, and then insert the 10x55.
13) Connect the bottom of the shock to the lift bracket using a 10x55 hex bolt and 10mm lock nut.
