2.5.2. Rebooting the EVS Server
To reboot the EVS server is not running in a given configuration, press B from the
Multicam Setup window, then RIGHT ARROW and ENTER to validate the action.
To reboot the EVS server when it is running in a given configuration, press ALT+Q when
you are in the Clip or Playlist page, then press ENTER to confirm the action.
2.5.3. Hardware Check
Overview on the Hardware Check
Purpose
During the hardware check, the following actions are performed:
• Retrieving and checking relevant information related to the various boards installed on
the EVS server
• Verifying the validity of the data recorded on the video disk array
The hardware check is only available in the server-based application.
Tip
Hardware check is also used to rebuild the video and audio information after
replacing a faulty disk.
Process
The hardware check runs the same steps and checks as the server boot process :
1. MTPC check
2. H3X or HCTX check
3. Video Codec check
4. Quad booting
5. GigE download
6. Disk check
7. Data loading
After you have launched the hardware check by pressing H in the Multicam Setup
window, the system automatically starts the test process.
One after the other, the various steps are displayed in the BOOT.H3X or BOOT.HCTX
window. The test process is completed when the H3X or HCTX board is initialized.
At the end of the hardware check, the hardware revisions information is displayed. The
information is logged in the bootwins.log.
