Displayed information On M/S Meaning
Connected to master On Slave
server The EVS server is available and the SDTI
connection is established between the Master
and the Slave servers.
Connected to slave On Master
server The EVS server is available and the SDTI
connection is established between the Master
and the Slave servers.
Error: not connected to
master
On Slave
server The Master server is not available on the
routing.
Error: not connected to
slave
On Master
server The Slave server is not available on the routing.
Error: No SDTI between
master and slave On Slave
server No SDTI connection is established between
the Master EVS server and the Slave EVS
server.
Error: No SDTI between
slave and master On Master
server No SDTI connection is established between
the Master and Slave EVS servers.
1.3. User Interface
1.3.1. Edit While Playout Control Panel
Introduction
When the EWP mode is active, the EWP Control Panel is displayed on the main IPEdit
window, between the Browser and the Timeline pane:
The EWP Control Panel makes it possible to:
• Control the TLO playout
• Perform synchronization actions between both TLOs in a Master/Slave configuration
• Get the nowline positions, and useful duration information in the Edit While Playout
mode
• Commit the changes from the TLE to the TLO.
The various buttons and fields available in the EWP Control Panel are described in the
following sections.
