IP Director Version 4.4 – User Manual – Part 4 – System Management & Troubleshooting

EVS Broadcast Equipment – March 2008

Issue 4.4.B

11

1.3 SHUTTLEPRO CONFIGURATION

1.3.1 I

NTRODUCTION

ShuttlePRO has a Jog wheel and a Shuttle ring, and fifteen buttons. The two top

rows of buttons on the ShuttlePRO series have labels for quick reference as to
which functions each button is designed to perform.

Since version 4 of IP Director, the ShuttlePRO driver is no more needed. IP
Director accesses directly to this human device. The button configuration is now
hard coded.

1.3.2

The controller has different functions depending on which mode the IP Director is
being operated in. The long buttons on the lower part of the controller have a

different function at either end. Other buttons have CTRL or SHIFT from the
keyboard as a modifier to change the button function. These functions are shown
in red for CTRL and blue for SHIFT in the diagrams below.

Details on the button functions are included in the Control Panel section of the
manual. The diagrams below are quick reference guides to the location of the

functions.

B

UTTON

C

ONFIGURATION
