Xedio Suite Version 4.1 - User Manual – Xedio Manager
EVS Broadcast Equipment – December 2011
Issue 4.1.D
75
Import
%SDDAY Shooting Date – Day
Number
%GUID Clip GUID
Use Long Clip Name When selected: the long clip name is used as media label.
Vumeter
Bottom level of
Vumeter
Field to define the db value of vu-meter bottom level. It is
the audio level difference (in dB) compared the 0 level
(audio level of the source media) and corresponding to
the bottom of the green zone in the audio meters
Saturation level of
Vumeter
Field to define the db value of vu-meter saturation level.
It is the audio level difference (in dB) compared to the 0
level (audio level of the source media) and corresponding
to the bottom of the red zone in the audio meters
Top level of Vumeter Field to define the db value of vu-meter top level. It is the
audio level (in dB) of the source media and corresponds
to the top of the red zone in the audio meters.
Warning level of
Vumeter
Field to define the db value of vu-meter warning level.
This value corresponds to the beginning of the orange
area in the vu-meter.
Note
The default values for audio vumeter levels differ in Xedio and in Final
Cut Pro.
It is therefore normal to see the same media reaching the red zone in
Xedio while it is still in the orange zone in FCP.
If you want to have the same audio meter display in both applications,
you can match the audio meter default values in Xedio Manager to the
FCP values.
9.2.4 L
IST OF
P
ARAMETERS FOR
X
EDIO
M
ANAGER
The Xedio Manager profile gives access to the following lists of parameters (tabs).
General
Convert IP to Machine
Name
When selected: the IP address is converted to machine
name for display.
