Page 3
292-2880 Rev. B
Page 3 of 10
07/12/11
SC4200
SportLift III
Installation Instructions
Parts List
Ref. No. Qty.
Part #
Description
1 SC9000 Receiver
Hitch
(Optional-Recommended)
2
1
202-0090
3/8”-16 Hex NYL. INS. Lock Nut, ZP
3
2
203-0003
3/8” Flat Washer, ZP
4
2
203-0010
3/8” Lock Washer, ZP
5
2
201-0760
3/8”-16 x 1-1/4” Hex Bolt, Grade 8, ZP
6 1 61-6273
Weldment,
Arm
Assembly,
DS
7
3
202-0002
5/16”-18 Hex Nut, ZP
8
3
203-0009
5/16” Lock Washer, ZP
9
3
203-0002
5/16” Flat Washer, ZP
10
3
201-0121
5/16”-18 x 1” Carriage Bolt, Grade 5, ZP
11
1 229-0640
Tire
Support,
5-1/2”
12
4
200-1727
Pin, 3/4” x 4” Eff., ZP, W/Clip
13
1
61-6253
Weldment, Base, DS, Overbilt
14
6
203-0011
7/16” Lock Washer, ZP
15
6
201-0451
7/16”-14 x 1-1/4” Hex Bolt, Grade 5, ZP
16
1 61-6255
Weldment,
Towing
Receiver,
Overbilt
17
4
202-0128
7/16”-14 Nylon Lock Nut
18
6
203-0091
7/16” SAE Flat Washer, ZP
19
4
201-0791
7/16”-14 x 3” Hex Bolt, Grade 5, ZP
20
2
102-6608
Light Bracket, Sport Carrier
21
2 294-0880
Light,
Tail,
Round
22
4
202-0102
1/4”-20 Hex Nylon Nut, ZP
23
4
203-0001
1/4” Flat Washer, ZP
24
1 101-6984
Deck,
Overbilt
25
4
201-0509
1/4”-20 x 3/4” Carriage Bolt, Grade 5
26
2
200-1483
Pin, 5/8” x 3” Eff., W/Clip
27
1 61-6272
Weldment,
Arm
Assembly,
PS
28
1
61-6277
Weldment, Winch Mount, Overbilt
29
2
200-0931
Lock Pin, 3/8” x 2-1/2”
30
2
229-0718
Snatch Block, Cross Built, 3/16” x 2” 8000L
31
1 61-6275
Weldment,
Pickup
Tube,
Overbilt
32
1 62-3613
Assembly,
Winch,
Overbilt
33
1
61-6254
Weldment, Base, PS, Overbilt
34
1
229-0724
D-Shackle, 3/8” x 21/32” x 7/16” x1-7/16” Ga.
1
294-0904
Quick Disconnect, Superwinch (not shown)
