29/11/2007 16.07.00
Reflow Soldering Information
All Components should be soldered according to
IPC/JEDEC J-STD-020C temperature-profile
for leadfree reflow-soldering (maximum values):
A P Products GmbH High Temperature Headers
Solder Profile
Profile Feature Pb-Free assembly
Average Ramp-Up Rate (Ts
max
to T
p
) 3 °C / second max.
Preheat
- Temperature Min (Ts
min
)
- Temperature Max (Ts
max
)
- Time (ts
min
to ts
max
)
150°C
200°C
60-180 seconds
Time maintained above:
- Temperature (T
L
)
- Time (t
L
)
217°C
60-150 seconds
Peak/Classification Temperature (T
p
) 260°C +/- 5°C
Time within 5°C of actual Peak
Temperature (t
p
)
10-15 seconds
Ramp-Down Rate 6°C / second max.
Time 25°C to Peak Temperature 8 minutes max.
Engineering Note:
The information presented in this
datasheet is accurate to the best of
our knowledge.
Due to ongoing efforts to advance
design and material performance,
this information is subject to change
without notice.
