A P Products Male and Female Header - Manual (Page 39)

Custom Header Design Aid
Single Row Male Headers
Tolerances: ± 0,20 mm (unless otherwise specified)
Special tolerance needed: ± ________ / + ________ / -________
Dimensions:
A:
_____________
B:
_____________
C:
_____________
Dimensions:
A:
_____________
B:
_____________
C:
_____________
Dimensions:
A:
_____________
B:
_____________
Plating:
3,00 µm Sn100 all over
0,25 µm Au all over
0,76 µm selective Au (on interface Area), 3,00 µm Sn100 on Solder side
Other (please specify):_____________________________________________________
Temperature Requirements
Standard Range (230°C solder temp, 10 sec.; Operating Temp: -40°C to +105°C)
High Temperature Range (260°C solder temp, 10 sec.; Operating Temp: -40°C to +230°C)
