ﺏﻮﻠﺳﺍ ﺐﺴﺣ ﻩﺬﻫ ﺕﲈﻴﻠﻌﺘﻟﺍ ﰲ ﺭﻮﻛﺬﳌﺍ ﺕﺍﺯﺍﺰﺘﻫﻻﺍ یﻮﺘﺴﻣ ﺱﺎﻴﻗ ﻢﺗ ﺪﻘﻟ
ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺩﺪﻌﻟﺍ ﺔﻧﺭﺎﻘﳌ ﻪﻣﺍﺪﺨﺘﺳﺍ ﻦﻜﻤﻳﻭ EN 60745 ﻦﻤﺿ ﲑﻌﻣ ﺱﺎﻴﻗ
.ﻲﺋﺪﺒﻣ ﻞﻜﺸﺑ ﺕﺍﺯﺍﺰﺘﻫﻼﻟ ﺽﺮﻌﺘﻟﺍ ﺮﻳﺪﻘﺘﻟ ﻢﺋﻼﻣ ﻪﻧﺃ ﲈﻛ .ﺾﻌﺒﻟﺍ ﺎﻬﻀﻌﺒﺑ
.ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻠﻟ ﺔﻴﺳﺎﺳﻻﺍ ﺕﺎﻣﺍﺪﺨﺘﺳﻻﺍ ﺭﻮﻛﺬﳌﺍ ﺕﺍﺯﺍﺰﺘﻫﻻﺍ یﻮﺘﺴﻣ ﻞﺜﻤﻳ
ﻭﺃ ﺔﻔﻟﺎﳐ ﻞﻐﺷ ﺩﺪﻌﺑ یﺮﺧﺃ ﺕﺎﻣﺍﺪﺨﺘﺳﻻ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﻝﲈﻌﺘﺳﺍ ﻢﺗ ﻥﺇ ﲈﻨﻴﺑ
ﺽﺮﻌﺘﻟﺍ ﻚﻟﺫ ﺪﻳﺰﻳ ﺪﻗﻭ .ﺕﺍﺯﺍﺰﺘﻫﻻﺍ یﻮﺘﺴﻣ ﻒﻠﺘﳜ ﺪﻘﻓ ،ﺔﻴﻓﺎﻛ ﲑﻏ ﺔﻧﺎﻴﺼﺑ
.ﺢﺿﺍﻭ ﻞﻜﺸﺑ ﻞﻐﺸﻟﺍ ﺓﱰﻓ ﻝﺍﻮﻃ ﺕﺍﺯﺍﺰﺘﻫﻼﻟ
ﺓﺎﻋﺍﺮﻣ ﻢﺘﻳ ﻥﺃ ،ﻖﻴﻗﺩ ﻞﻜﺸﺑ ﺕﺍﺯﺍﺰﺘﻫﻼﻟ ﺽﺮﻌﺘﻟﺍ ﺮﻳﺪﻘﺗ ﻞﺟﺃ ﻦﻣ ﻲﻐﺒﻨﻳ ﲈﻛ
ﻞﻤﺤﺑ ﻪﻠﻴﻐﺸﺗ ﻥﻭﺩ ﻦﻜﻟﻭ ﺎﲠ ﻞﻤﻌﻳ ﻲﺘﻟﺍ ﻭﺃ ﺯﺎﻬﳉﺍ ﺎﳍﻼﺧ ﺄﻔﻄﻳ ﻲﺘﻟﺍ ﺕﺎﻗﻭﻷﺍ
ﺓﺪﻣ ﻞﻣﺎﻛ ﱪﻋ ﺢﺿﺍﻭ ﻞﻜﺸﺑ ﺕﺍﺯﺍﺰﺘﻫﻼﻟ ﺽﺮﻌﺘﻟﺍ ﻚﻟﺫ ﺾﻔﳜ ﺪﻗﻭ .ﻼﻌﻓ
.ﻞﻤﻌﻟﺍ
:ﻼﺜﻣ ،ﺕﺍﺯﺍﺰﺘﻫﻻﺍ ﲑﺛﺄﺗ ﻦﻣ ﻡﺪﺨﺘﺴﳌﺍ ﺔﻳﺎﻗﻮﻟ ﺔﻴﻓﺎﺿﺇ ﻥﺎﻣﺃ ﺕﺍﺀﺍﺮﺟﺇ ﺩﺪﺣ
.ﻞﻤﻌﻟﺍ ﺕﺎﻳﺮﳎ ﻢﻴﻈﻨﺗﻭ ﻦﻳﺪﻴﻟﺍ ﺔﺌﻓﺪﺗ ،ﻞﻐﺸﻟﺍ ﺩﺪﻋﻭ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ ﺔﻧﺎﻴﺻ
ﻖﻓﺍﻮﺘﻟﺍ ﺢﻳﴫﺗ
ﻖﻓﺍﻮﺘﻳ “ﺔﻴﻨﻔﻟﺍ ﺕﺎﻧﺎﻴﺒﻟﺍ” ﰲ ﻑﻮﺻﻮﳌﺍ ﺞﺘﻨﳌﺍ ﻥﺄﺑ ،ﺎﻨﺘﻴﻟﻭﺆﺴﻣ ﯽﻠﻋ ﺡﴫﻧ ﺎﻨﻧﺇ
ﺕﺍﺩﺎﺷﺭﺇ ﻡﺎﻜﺣﺃ ﺐﺴﺣ EN 60745 :ﺔﻴﻟﺎﺘﻟﺍ ﺔﻳﺭﺎﻴﻌﳌﺍ ﻖﺋﺎﺛﻮﻟﺍ ﻭﺃ ﲑﻳﺎﻌﳌﺍ ﻊﻣ
. 2006/42/EG ، 2004/108/EG ، 2011/65/EU
: (2006/42/EG) یﺪﻟ ﺔﻴﻨﻔﻟﺍ ﻕﺍﺭﻭﻷﺍ
Robert Bosch GmbH, PT/ETM9,
D-70745 Leinfelden-Echterdingen
Helmut Heinzelmann
Head of Product Certification
PT/ETM9
Dr. Egbert Schneider
Senior Vice President
Engineering
Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
28.03.2012
ﺐﻴﻛﱰﻟﺍ
ﯽﻠﻋ ﻞﻤﻋ ﻱﺃ ﺀﺍﺮﺟﺇ ﻞﺒﻗ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺔﻜﺒﺸﻟﺍ ﺲﺒﻘﻣ ﻦﻣ ﺲﺑﺎﻘﻟﺍ ﺐﺤﺳﺍ ◀
.ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ
ﺔﻳﺎﻗﻮﻟﺍ ﺕﺍﺰﻴﻬﲡ ﺐﻴﻛﺮﺗ
.ﻡﺪﺨﺘﺴﳌﺍ ﻩﺎﲡﺎﺑ ﺭﴩﻟﺍ ﺮﻳﺎﻄﺗ ﻊﻨﲤ ﺚﻴﺤﺑ ﺔﻳﺎﻗﻮﻟﺍ ﺔﻴﻄﻏﺃ ﻂﺒﺿﺍ ◀
( A ﺓﺭﻮﺼﻟﺍ ﻊﺟﺍﺮﺗ) (GGS 6 S) ﺦﻠﺠﻠﻟ ﺔﻳﺎﻗﻭ ﺀﺎﻄﻏ
ﻊﻣ 2 ﺔﻳﺎﻗﻮﻟﺍ ﺀﺎﻄﻏ ﻊﺿﻭ ﻢﺋﻻ .ﻥﺍﺭﻭﺪﻟﺍ ﺭﻮﳏ ﻖﻨﻋ ﯽﻠﻋ 2 ﺔﻳﺎﻗﻮﻟﺍ ﺀﺎﻄﻏ ﺰﻛﺭ
ﺪﺷﻭ 14 ﺖﻴﺒﺜﺘﻟﺍ ﺐﻟﻮﻟ ﺔﻄﺳﺍﻮﺑ 2 ﺔﻳﺎﻗﻮﻟﺍ ﺀﺎﻄﻏ ﺖﹼﺒﺛ.ﻞﻤﻌﻟﺍ ﺔﻠﺣﺮﻣﺕﺎﺒﻠﻄﺘﻣ
.ﻞﻗﻷﺍ ﯽﻠﻋ ﱰﻣ ﻦﺗﻮﻴﻧ 10 ﻎﻠﺒﻳ ﺪﺷ ﻥﺍﺭﻭﺩ ﻡﺰﻌﺑ ﺖﻴﺒﺜﺘﻟﺍ ﺐﻟﻮﻟ
( E ﺓﺭﻮﺼﻟﺍ ﻊﺟﺍﺮﺗ) (GGS 6) ﺦﻠﺠﻠﻟ ﺔﻳﺎﻗﻭ ﺀﺎﻄﻏ
11 ﺔﻳﺎﻗﻮﻟﺍ ﺀﺎﻄﻏ ﻊﺿﻭ ﻢﺋﻻ .ﻥﺍﺭﻭﺪﻟﺍ ﺭﻮﳏ ﻖﻨﻋ ﯽﻠﻋ 11 ﺔﻳﺎﻗﻮﻟﺍ ﺀﺎﻄﻏ ﺰﻛﺭ
ﺖﻴﺒﺜﺘﻟﺍ ﻲﺘﻟﻮﻣﺎﺻ ﺔﻄﺳﺍﻮﺑ 11 ﺔﻳﺎﻗﻮﻟﺍ ﺀﺎﻄﻏ ﺖﺒﺛ .ﻞﻤﻌﻟﺍ ﺓﻮﻄﺧ ﺕﺎﺒﻠﻄﺘﻣ ﻊﻣ
.ﻞﻗﻷﺍ ﯽﻠﻋ ﱰﻣ ﻦﺗﻮﻴﻧ 10 ﺭﺍﺪﻘﻤﺑ ﺖﻴﺒﺜﺘﻟﺍ ﻲﺘﻟﻮﻣﺎﺻ ﺪﺷﻭ 19
ﲔﺘﻟﻮﻣﺎﺼﻟﺍ ﺪﺷ ﻢﻜﺣﺍﻭ ﺦﻠﳉﺍ ﺓﺪﻋ ﺐﻴﻛﺮﺗ ﺪﻌﺑ 11 ﺔﻳﺎﻗﻮﻟﺍ ﺀﺎﻄﻏ ﻖﻠﻏﺍ
.ﲔﺘﺤﻨﺠﳌﺍ
ﺔﻴﻨﻔﻟﺍ ﺕﺎﻧﺎﻴﺒﻟﺍ
GGS 6 S GGS 6 ﺔﻤﻴﻘﺘﺴﻣ ﺔﺧﻼﺟ
0 601 214 1.. 0 601 214 0.. ﻒﻨﺼﻟﺍ ﻢﻗﺭ
1 150 1 200 ﻁﺍﻭ ﺔﻴﻨﻘﳌﺍ ﺔﻴﻤﺳﻻﺍ ﺓﺭﺪﻘﻟﺍ
670 720 ﻁﺍﻭ ﺓﺎﻄﻌﳌﺍ ﺓﺭﺪﻘﻟﺍ
6 800 6 800 ١- ﺔﻘﻴﻗﺩ ﯽﺼﻗﻷﺍ ﻥﺍﺭﻭﺪﻟﺍ ﺩﺪﻋ
M 14 5/8 " ﺔﺧﻼﳉﺍ ﻥﺍﺭﻭﺩ ﺭﻮﳏ ﺔﺒﻟﻮﻟ ﻥﺎﻨﺳﺃ
31 27 ﻢﻣ ﯽﺼﻗﻷﺍ ﻥﺍﺭﻭﺪﻟﺍ ﺭﻮﳏ ﻝﻮﻃ
20 16
ﻢﻣ ﺓﺪﻌﻟﺍ ﻦﺿﺎﺣ
32 25 ﻢﻣ ﯽﺼﻗﻷﺍ ﺦﻠﳉﺍ ﺹﺍﺮﻗﺃ ﻦﺨﺛ
125 125 ﻢﻣ ﯽﺼﻗﻷﺍ ﺦﻠﳉﺍ ﺕﻼﺠﻋ ﺮﻄﻗ
3,9 3,9 ﻎﻛ EPTA-Procedure 01/2003 ﺐﺴﺣ ﻥﺯﻮﻟﺍ
II / II /
ﺔﻳﺎﻗﻮﻟﺍ ﺔﺌﻓ
.ﺔﻨﻴﻌﻣ ﻥﺍﺪﻠﺒﺑ ﺔﺻﺎﺧ ﺕﺍﺯﺍﺮﻄﺑ ﻭﺃ ﻚﻟﺫ ﻦﻋ ﺪﻬﳉﺍ ﻒﻠﺘﳜ ﺎﻣﺪﻨﻋ ﻢﻴﻘﻟﺍ ﻩﺬﻫ ﺕﻭﺎﻔﺘﺗ ﺪﻗ .ﻂﻟﻮﻓ 230 ﺭﺍﺪﻘﻤﺑ [U] ﻲﻤﺳﺍ ﺪﻬﳉ ﻝﻮﻌﻔﳌﺍ ﺔﻳﺭﺎﺳ ﻢﻴﻘﻟﺍ
ﻦﻋ ﺔﻜﺒﺸﻟﺍ ﺔﻗﻭﺎﻌﻣ ﺖﻠﻗ ﻥﺇ .ﺔﻤﺋﻼﻣ ﲑﻏ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺔﻜﺒﺸﻟﺍ ﻑﻭﺮﻇ ﺖﻧﺎﻛ ﻥﺇ یﺮﺧﻷﺍ ﺓﺰﻬﺟﻷﺍ ﯽﻠﻋ ﺶﻳﻮﺸﺗ ﺃﺮﻄﻳ ﺪﻗ .ﻲﺋﺎﺑﺮﻬﻜﻟﺍ ﺪﻬﳉﺎﺑ ﺰﻴﺟﻭ ﺽﺎﻔﺨﻧﺍ ﻞﻴﻐﺸﺘﻟﺍ ﺕﺍﺭﻭﺩ ﺞﺘﻨﺗ
.ﻞﻠﺧ ﻱﺃ ﻊﻗﻮﺘﻟ ﹺﻉﺍﺩ ﻼﻓ ،ﻡﻭﺃ 0,36
