To view the VOR Position page:
1. Make sure the cursor is not flashing. If it is, press
C
.
2. Rotate
O
until the VOR Position page is displayed.
‘dme’ or ‘tacan’ is displayed on the bottom line of the VOR Position page if there
is a DME or TACAN facility also located with the VOR. The ‘wx bdcst’ indicates that
the VOR also transmits weather information. The station declination displayed on the
top right is the magnetic orientation to which the VOR is set.
32
REFERENCE
VOR Position Page
Section
2
Waypoint type
and identifier
Weather
Frequency
Location
(lat/lon)
DME/TACAN
Station
Declination
VOR Position page
