US B Pin # Def inition
1 USB_VCC5
2 USB _A-
3 USB_A+
4 GND
APPENDIX B
M12 USB Connector D efinition for Lab Test
Fema le M 12 LAN cable (Inter nal)
Internal P IN Definition for M 12 connector, 8 -pin
M 12 Pin # Defini tion M 12 Pin # D efi nition
1 U SB_VCC5 2 U SB_A-
3 USB _A+ 4 GND
5 U SB_VCC5 6 U SB_B-
7 U SB_B+ 8 GND
M ale M1 2 L AN evaluation cable (Exter nal)
M12 Pi n # D efi niti on
1 U SB_VCC5
2 USB_A-
3 U SB_A+
4 GND
