2. GPRS JTAG(Pitch 2 .0 mm) [GPR S Boa rd Location: CN2 ]
Pin Signal Pin Signal
1 2.6V 2 2 .6 V
3 TRST# 4 GND
5 TDI 6 GND
7 TMS 8 GND
9 TCK 10 GND
11 RTCK 12 GND
13 TDO 14 GND
15 RESET# 16 GND
17 P ul l down 18 GND
19 P ul l down 20 GND
3. GSM Module Connector(Pitch 2.0 mm ) [GPRS Boa rd Location: CN8 ]
Pin Signal Pin Signal
1 M IC_P 2 3.3V
3 MIC_N 4 GND
5 SP K_P 6 GPIO_1
7 SPK_N 8 USIM _PWR
9 GND 10 USI M_DATA
11 VC C_MSM26_DIG 12 USIM_CLK
13 NC 14 USIM _RESET
15 GND 16 GPIO_2
17 NC 18 GND
19 NC 20 W_DI SABLE#
21 GND 22 AUXV1
23 NC 24 3.3V
25 NC 26 GND
27 GND 28 GPIO_3
29 GND 30 RESERVED
31 NC 32 RESERVED
33 M DL_RESE T_N 34 GND
35 GND 36 USB_D -
37 GND 38 USB_D+
39 3.3V 40 GND
41 3.3V 42 LED_WWAN#
43 GND 44 GPIO_4
45 PC M_CLK 46 GPIO_5
47 PCM _DIN 48 GPIO_6
49 PCM_DOUT 50 GND
51 PC M_SYNC 52 3.3V
