Acnodes FES 7035 - Manual (Page 4)

FES7035
Fanless Embedded System
Table of Contents
Copyright .................................................................................................................. 2
Trademarks ............................................................................................................... 2
Stati c Electric ity Precautions .................................................................................... 2
Safety Measures ....................................................................................................... 3
Wa rranty ........................................................... ........................................................ 3
Chapter 1: Introduction
1 -1 O verview.............................................................................................................. 5
1 -2 P roduct Specification........................................................................................... 6
1 -3 System Block Diagram ......................................................................................... 8
1 -4 M echanical Diagram ...........................................................................................
9
1 -5 Front and Rear I/O …............................................................................................ 10
Chapter 2: Pin D efinition & Jumper Settings
2 -1 Front panel Pin Definiti on………………………………… ……… ………….............…… ………
11
2 -2 Rear Panel P in Defi nition………………………………… ……… ……………………………………. 12
2 -3 Internal P in Defi ni ti on & Jum pe r Settings… ……………………………………………………. 16
2-3 .1 Main Board Top V iew ………………………….………………………………………… …… . 16
2 -3.2 M ain Board Pin Definition & Jumper Settings……………… ………………………. 17
2 -3.3 Jum per Settings……… .………………………….……………………………………… ……….
23
2 -4 G PRS Board P in Definition & Jum per Settings………….……………… ………………………. 26
Chapter 3: Software Support G uide
3 -1 Dr iver Installation……………….………………… …………… ………………………………………….
30
3 -2 G PRS M odule Software Program ming…………………………… ……………………………… 30
Chapter 4: BIOS Setup Menu
4 -1 BIOS Configuration Overview ……… ………………………………………………………………….
36
4 -2 Entering BIO S Setup…………………………………… …………… ……………………………………… 36
4 -3 A dvanced CMOS Features… …………………………………………… ………………………………… 39
4 -4 Other BIO S Features……… …………… ..…………………………………………………………………. 46
4 -5 Security Features ….……..………………………………… ……… ………………………………….….. 47
4 -6 Boot M anagem ent Setup ..…………………… ………………………………………..……………... 48
4 -7 Exit BIOS Setup ……………………… .……..…………………………………………………….……..…. 49
Appendix A: GHOST Recovery Guide …………………………………………………………………… 50
Appendix B: M 12 USB Connector De finition for Lab Test..…………………………………… 56
14628 Central Ave,
Chino, CA 91710
tel:909.597.7588, fax:909.597.1939
© Copyright 2013 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes’ web site at www.acnodes.com.
