4. GPRS/GPS Reset [GPRS Boa rd L ocation: JP3 ]
Default Pin Status
 1-2 ( Open) Default
1-2 ( Short) Reset
5. Ignition Function (Pitch 2 .0 mm ) [GPRS Board Location: JP4]
Default Pin Status
 1-2 ( Short) E nable Ignition Function
2-3 ( Short) Dis able Ig nition Function
6. Programming firmware (Pitch 2 .0 mm) [GPRS Board Location: SW2]
Pin1 Pin2 Pin3 Pin4 Main Board
ON ON OFF O FF Norm al Status
(default)
O FF OFF ON O N Program ming
firm ware
7. Select voltage input (Pitch 2.0 mm) [G PRS Boa rd Location: SW3.1 & SW3.2]
SW3 .1 SW3.2
12 V
O N O N
24 V OFF O N
