2-3.3Jum per Settings
1. Power ON Select [Boa rd Location: JP7]
D ef aul t Jumper Selector Po wer ON Select
1-2 Auto Power ON
x 2-3 Button POWER ON
2. B utton Select [Board Location: JP1 3]
D ef aul t Jumper Selector Button Sel ect
x 1-2 Pow er ON Button
2-3 System Reset Button
3. Power IN Control Select [Board Location: JP12]
D ef aul t Jumper Selector Power IN
x 1-2 Power I n Without Control
2-3
Power I N control by Ignition or
Externa l M CU or External Ba ttery
Ignition
4. Ignition Select [Board Location: JP14]
D ef aul t Jumper S el ector Igni tion Control
x 1-2 Short Power ON Button
1-2 Open System R eset Button
5. CMOS Cle ar (Jum pe r_ 2.0mm ) [Board Location: JP5]
D ef aul t Jumper Selector CM OS
x 1-2 Short Norm al
2-3 Short CMOS Clea r
6. LV DS 1 Powe r Sele ct [Board Location: JP1]
PIN Si gnal
1 3.3V
2 L1_PWR
3 5V
D ef aul t Jumper Selector LVDS 1 Power
x 1-2 3.3V
2-3 5V
