7. Internal KB/M ouse Connector (WTB_1X 6_2.0m m _Male_ DIP ) [Board Location: J9]
PIN S ignal
1 M_CLK
2 +5V
3 M_DATA
4 KB_DATA
5 G ND
6 KB_C LK
8. M ini PCI Socke t 1, 2 (Mini P CI_ 124P in_ 8mm _SMD) [Board Location: CN 2, CN 3 ]
Socket Locati on S ignal D efault
PCI -E1 CN2 Mini PCI -E & mSATA m SATA
PCI -E2 CN3 Mini PCI-E
9. External USB Port 1 ~2 [Board Location: USB1 ]
Exte rnal U SB Port 3 ~4 [Board Location: USB2]
10. Internal USB Port 1 ~2 [Board Location: CN 1]
Inte rnal U SB Port 3 ~4 [Board Location: CN 5]
PIN Signal PIN S ignal
1 USB_POWER 5 USB _POWE R
2 U SB1_DATA- 6 U SB2_DATA-
3 USB1_DATA+ 7 USB 2_DATA+
4 GND 8 G ND
11. Internal LED Conne ctor [Boa rd Location: J6]
PIN Sig nal
1 Pow er LED+
2 Pow er LE D-
3 HD D LED+
4 HDD LE D-
12. Power & Reset Button Connector [Boa rd Location: J7]
PIN Sig nal
1 PWR _BU T _IN
2 PWR_BU T_GND
3 RST_BU T_IN
4 RST_BUT _G ND
