Acnodes FES 7035 User Manual

Page 15

background image

USB Pin #

Defini tion

1

USB _VCC 5

2

U SB_A-

3

USB _A+

4

GND

8. Female M1 2 U SB Conne ctor

Internal P IN Defi ni ti on for M12 conne ctor, 8-pi n

M 12 Pin #

Defi niti on

M 12 Pin #

Definition

1

G ND

2

G ND

3

U SB_A+

4

U SB_B+

5

U SB_A-

6

USB_B-

7

U SB_VCC5

8

U SB_VCC5

9. Male M 12 USB evaluation cable (Exte rna l)

M 12 Pin #

Definition

1

GND

3

U SB_A+

5

U SB_A-

7

USB _VCC 5
