FPC 6104
10.4” Industrial Fanless Panel PC
Step 3: Secure the connector. Secure the serial device connector to the external inter-
face by tightening the two retention screws on either side of the connector.
4.11.4 USB Device Connection
To connect a USB 2.0 or USB 1.1 device, please follow the instructions below.
Step 1: Locate the USB connectors. The locations of the USB connectors are shown
in Chapter 2.
Step 2: Align the connectors. Align the USB device connector with one of the connec-
tors on the bottom panel. See Figure 4-36.
