FPC 6104

10.4” Industrial fanless Panel PC

4.9.5 Clear CMOS Jumper

Jumper Label:

J_CMOS1

Jumper Type:

3-pin header

Jumper Settings:See Table 4-5
Jumper Location:

See Figure 4-18

If the FPC6104 fails to boot due to improper BIOS settings, the clear CMOS jumper
clears the CMOS data and resets the system BIOS information. To do this, use the
jumper cap to close pins 2 and 3 for a few seconds then reinstall the jumper clip back to
pins 1 and 2.

If the "CMOS Settings Wrong" message is displayed during the boot up process, the
fault may be corrected by pressing the F1 to enter the CMOS Setup menu. Do one of
the following:

Enter the correct CMOS setting
Load Optimal Defaults
Load Failsafe Defaults.

After having done one of the above, save the changes and exit the CMOS Setup menu.
The clear CMOS jumper settings are shown in Table 4-5.
